首先説明一下我的環境:

  • 硬件:NVIDIA Jetson Xavier NX
  • tensorflow-gpu==2.2.0
  • onnx==1.7.0
  • tf2onnx==1.7.1
  • cuda=10.2
  • cudnn=7.6.5

我主要是想把yolov4-deepsort的tenosorflow模型轉換為tensorrt模型,然後在NVIDIA Jetson Xavier NX設備上部署,但yolov4-deepsort官網並沒有給出如何把模型轉換為TensorRT,可以看這個issues


1 安裝tensorflow-onnx環境和把tensorflow的pb模型轉換為onnx模型

1.1 安裝tensorflow2onnx環境

1、去tensorflow-onnx克隆倉庫

tensorflow2onnx的githu官網:https://github.com/onnx/tensorflow-onnx

2、克隆倉庫

git clone https://github.com/onnx/tensorflow-onnx

3、安裝tensorflow-onnx

python setup.py install

python setup.py develop

1.2 把tensorflow的pb模型轉換為onnx模型

1.2.1 把tensorflow的pb模型轉換為onnx模型

1、首先看一下我的tensorflow模型的文件的目錄結構

```python (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ tree . └── yolov4-tiny-416 ├── assets ├── saved_model.pb └── variables ├── variables.data-00000-of-00001 └── variables.index

3 directories, 4 files (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ ```

2、使用如下命令把pb模型轉換為onnx模型

python -m tf2onnx.convert --saved-model checkpoints/ --output saved_model.onnx

執行命令,如下可以看出成功執行:

python -m tf2onnx.convert --saved-model yolov4-tiny-416/ --output saved_model.onnx --opset 10

``python (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ python -m tf2onnx.convert --saved-model yolov4-tiny-416/ --output saved_model.onnx --opset 10 2020-10-27 20:29:41,173 - WARNING - '--tag' not specified for saved_model. Using --tag serve 2020-10-27 20:29:44,329 - INFO - Signatures found in model: [serving_default]. 2020-10-27 20:29:44,329 - WARNING - '--signature_def' not specified, using first signature: serving_default WARNING:tensorflow:From /home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/tf_loader.py:413: extract_sub_graph (from tensorflow.python.framework.graph_util_impl) is deprecated and will be removed in a future version. Instructions for updating: Usetf.compat.v1.graph_util.extract_sub_graph2020-10-27 20:29:44,935 - WARNING - From /home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/tf_loader.py:413: extract_sub_graph (from tensorflow.python.framework.graph_util_impl) is deprecated and will be removed in a future version. Instructions for updating: Usetf.compat.v1.graph_util.extract_sub_graph` 2020-10-27 20:29:45,264 - INFO - Using tensorflow=2.2.0, onnx=1.7.0, tf2onnx=1.7.1/796841 2020-10-27 20:29:45,264 - INFO - Using opset 2020-10-27 20:29:45,686 - INFO - Computed 0 values for constant folding 2020-10-27 20:29:46,825 - INFO - Optimizing ONNX model 2020-10-27 20:29:47,516 - INFO - After optimization: BatchNormalization -19 (19->0), Cast -8 (28->20), Const -210 (282->72), Gather +2 (2->4), Identity -5 (5->0), Mul -1 (12->11), NonZero -1 (2->1), Reshape -1 (12->11), Shape -6 (12->6), Slice -2 (18->16), Squeeze -7 (8->1), Transpose -80 (90->10), Unsqueeze -38 (40->2) 2020-10-27 20:29:47,524 - INFO - 2020-10-27 20:29:47,524 - INFO - Successfully converted TensorFlow model yolov4-tiny-416/ to ONNX 2020-10-27 20:29:47,537 - INFO - ONNX model is saved at saved_model.onnx (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ ls

```

成功生成onnx模型

```python (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ tree . ├── saved_model.onnx └── yolov4-tiny-416 ├── assets ├── saved_model.pb └── variables ├── variables.data-00000-of-00001 └── variables.index

3 directories, 4 files (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ ```

1.2.2 轉可能報錯1:OSError: SavedModel file does not exist at: checkpoints//{saved_model.pbtxt|saved_model.pb}

然後就會報錯:OSError: SavedModel file does not exist at: checkpoints//{saved_model.pbtxt|saved_model.pb}

這個錯誤是由於--saved-model參數路徑不對,應該定位到yolov4-tiny-416目錄,(官網的issues

解決這個錯誤:

  • --saved-model參數後必須是存放.pb模型的目錄,而不是直接是.pb文件,例如:--saved-model checkpoint是正確的,--saved-model checkpoint/saved_model.pb是錯誤的寫法
  • .pb模型文件必須命令為:saved_model.pb`

.pb模型文件的命令和存放如下

```python (cuda10) shl@zhihui-mint:~/shl_res/1_project/deep_sort/pred_models$ tree checkpoint/ checkpoint/ └── saved_model.pb

0 directories, 1 file (cuda10) shl@zhihui-mint:~/shl_res/1_project/deep_sort/pred_models$ ```

1.2.3 轉可能報錯2:ValueError: StridedSlice: only strides=1 is supported

1、可能報錯:下面兩個錯誤原因是一樣的

  • ValueError: StridedSlice: only strides=1 is supported
  • NameError: name 'tf2onnx' is not defined

```python (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ python -m tf2onnx.convert --saved-model yolov4-tiny-416/ --output saved_model.onnx --opset 1

... Traceback (most recent call last): File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/tfonnx.py", line 286, in tensorflow_onnx_mapping func(g, node, kwargs) File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/onnx_opset/tensor.py", line 688, in version_1 raise ValueError("StridedSlice: only strides=1 is supported") ValueError: StridedSlice: only strides=1 is supported 2020-10-27 20:27:57,379 - ERROR - Unsupported ops: Counter({'FusedBatchNormV3': 19, 'Where': 2, 'ResizeBilinear': 1, 'GreaterEqual': 1}) Traceback (most recent call last): File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/runpy.py", line 193, in _run_module_as_main "main", mod_spec) File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/runpy.py", line 85, in _run_code exec(code, run_globals) File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/convert.py", line 185, in main() File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/convert.py", line 163, in main const_node_values=const_node_values) File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/tfonnx.py", line 528, in process_tf_graph raise exceptions[0] File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/tfonnx.py", line 286, in tensorflow_onnx_mapping func(g, node, kwargs) File "/home/shl/anaconda3/envs/yolov4/lib/python3.6/site-packages/tf2onnx/onnx_opset/tensor.py", line 969, in version_1 dst = tf2onnx.utils.ONNX_DTYPE_NAMES[dst] NameError: name 'tf2onnx' is not defined (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ conda deactivate (base) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$ conda activate yolov4 (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints$

```

2、錯誤解決方法

上面的兩個錯誤都是由於--opset參數的值設置的問題,可以參考這個issues,把參數設置為--opset 10

1.2.4 轉可能報錯3:RuntimeError: MetaGraphDef associated with tags 'serve' could not be found in SavedModel.

下面的這個錯誤並不是在Jetson Xavier NX上遇到的,這個是我轉換另外一個tensorflow的pb模型,由於這個pb模型是用tensorflow1.5.0生成的,而tensorflow-onnx支持的tensorflow版本至少要tensorflow1.12以上,因此才有這個錯誤:RuntimeError: MetaGraphDef associated with tags 'serve' could not be found in SavedModel. To inspect available tag-sets in the SavedModel, please use the SavedModel CLI:saved_model_cli``

```python (cuda10) shl@zhihui-mint:~/shl_res/1_project/deep_sort/pred_models$ python -m tf2onnx.convert --saved-model checkpoint --output mars-small128.onnx

2020-10-28 20:04:30,246 - WARNING - From /home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tf2onnx/verbose_logging.py:76: The name tf.logging.set_verbosity is deprecated. Please use tf.compat.v1.logging.set_verbosity instead.

2020-10-28 20:04:30,360 - WARNING - '--tag' not specified for saved_model. Using --tag serve Traceback (most recent call last): File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/runpy.py", line 193, in _run_module_as_main "main", mod_spec) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/runpy.py", line 85, in _run_code exec(code, run_globals) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tf2onnx/convert.py", line 185, in main() File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tf2onnx/convert.py", line 136, in main args.signature_def, args.concrete_function, args.large_model) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tf2onnx/tf_loader.py", line 337, in from_saved_model _from_saved_model_v1(sess, model_path, input_names, output_names, tag, signatures) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tf2onnx/tf_loader.py", line 231, in _from_saved_model_v1 imported = tf.saved_model.loader.load(sess, tag, model_path) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tensorflow/python/util/deprecation.py", line 324, in new_func return func(args, kwargs) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tensorflow/python/saved_model/loader_impl.py", line 269, in load return loader.load(sess, tags, import_scope, saver_kwargs) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tensorflow/python/saved_model/loader_impl.py", line 422, in load *saver_kwargs) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tensorflow/python/saved_model/loader_impl.py", line 349, in load_graph meta_graph_def = self.get_meta_graph_def_from_tags(tags) File "/home/shl/anaconda3/envs/cuda10/lib/python3.6/site-packages/tensorflow/python/saved_model/loader_impl.py", line 327, in get_meta_graph_def_from_tags "\navailable_tags: " + str(available_tags)) RuntimeError: MetaGraphDef associated with tags 'serve' could not be found in SavedModel. To inspect available tag-sets in the SavedModel, please use the SavedModel CLI: saved_model_cli available_tags: [set()] (cuda10) shl@zhihui-mint:~/shl_res/1_project/deep_sort/pred_models$ ls checkpoint detections detections-20201028T101110Z-001.zip networks networks-20201028T101118Z-001.zip tensorflow-onnx (cuda10) shl@zhihui-mint:~/shl_res/1_project/deep_sort/pred_models$ ```

2安裝onnx-tensorrt環境與onnx模型轉trt模型

2.1 安裝onnx-tensorrt環境

我下面的安裝過程主要參考官網的issues385

1、克隆你需要的onnx-tensorrt版本倉庫

git clone -b 7.1 --single-branch https://github.com/onnx/onnx-tensorrt.git

2、進入到代碼目錄

cd onnx-tensorrt/

python `zhihui@zhihui-desktop:~$ cd onnx-tensorrt/ zhihui@zhihui-desktop:~/onnx-tensorrt$ ls CMakeLists.txt ShapeTensor.hpp onnx2trt_common.hpp ImporterContext.hpp ShapedWeights.cpp onnx2trt_runtime.hpp LICENSE ShapedWeights.hpp onnx2trt_utils.cpp LoopHelpers.cpp Status.hpp onnx2trt_utils.hpp LoopHelpers.hpp TensorOrWeights.hpp onnx_backend_test.py ModelImporter.cpp builtin_op_importers.cpp onnx_tensorrt ModelImporter.hpp builtin_op_importers.hpp onnx_trt_backend.cpp NvOnnxParser.cpp common.hpp onnx_utils.hpp NvOnnxParser.h contributing.md operators.md OnnxAttrs.cpp docker setup.py OnnxAttrs.hpp getSupportedAPITest.cpp third_party README.md libnvonnxparser.version toposort.hpp RNNHelpers.cpp main.cpp trt_utils.hpp RNNHelpers.hpp nv_onnx_parser_bindings.i utils.hpp ShapeTensor.cpp onnx2trt.hpp zhihui@zhihui-desktop:~/onnx-tensorrt$

3、克隆該倉庫關聯的子倉庫

git submodule update --init --recursive

我之前由於網絡代理的原因,導致錯誤,所以在筆記本上更新的,然後把代碼再拷貝到服務器上的! ```python $ git submodule update --init --recursive Submodule 'third_party/onnx' (https://github.com/onnx/onnx.git) registered for path 'third_party/onnx' Cloning into 'E:/NVIDIAJetson/onnx-tensorrt/third_party/onnx'... Submodule path 'third_party/onnx': checked out '553df22c67bee5f0fe6599cff60f1afc6748c635' Submodule 'third_party/benchmark' (https://github.com/google/benchmark.git) registered for path 'third_party/onnx/third_party/ben chmark' Submodule 'third_party/pybind11' (https://github.com/pybind/pybind11.git) registered for path 'third_party/onnx/third_party/pybin d11' Cloning into 'E:/NVIDIAJetson/onnx-tensorrt/third_party/onnx/third_party/benchmark'... Cloning into 'E:/NVIDIAJetson/onnx-tensorrt/third_party/onnx/third_party/pybind11'... Submodule path 'third_party/onnx/third_party/benchmark': checked out 'e776aa0275e293707b6a0901e0e8d8a8a3679508' Submodule path 'third_party/onnx/third_party/pybind11': checked out '09f082940113661256310e3f4811aa7261a9fa05' Submodule 'tools/clang' (https://github.com/wjakob/clang-cindex-python3) registered for path 'third_party/onnx/third_party/pybind 11/tools/clang' Cloning into 'E:/NVIDIAJetson/onnx-tensorrt/third_party/onnx/third_party/pybind11/tools/clang'... Submodule path 'third_party/onnx/third_party/pybind11/tools/clang': checked out '6a00cbc4a9b8e68b71caf7f774b3f9c753ae84d5'

shl@shliangPC MINGW64 /e/NVIDIAJetson/onnx-tensorrt (7.1)

```

注意1:

如果在使用gitpip的時候遇到錯誤:Received HTTP code 503 from proxy after CONNECT,請參考這篇博客

注意2:

如果下面編譯的時候顯示Should resolve your "does not contain a CMakeLists.txt" error錯誤,就是應為你沒有克隆關聯的子倉庫,因此,上面的命令一定要執行!!!

4、安裝prototbuf及其依賴,如果你已經安裝可以跳過這一步

apt update -y && apt install -y libprotobuf-dev protobuf-compiler

```python zhihui@zhihui-desktop:~/onnx-tensorrt$ sudo apt update -y && apt install -y libprotobuf-dev protobuf-compiler Hit:1 http://ports.ubuntu.com/ubuntu-ports bionic InRelease
Hit:2 http://ports.ubuntu.com/ubuntu-ports bionic-updates InRelease
Hit:3 http://ports.ubuntu.com/ubuntu-ports bionic-backports InRelease
Hit:4 http://ports.ubuntu.com/ubuntu-ports bionic-security InRelease
Hit:5 https://repo.download.nvidia.cn/jetson/common r32.4 InRelease
Hit:6 https://repo.download.nvidia.cn/jetson/t194 r32.4 InRelease Reading package lists... Done
Building dependency tree
Reading state information... Done 6 packages can be upgraded. Run 'apt list --upgradable' to see them. E: Could not open lock file /var/lib/dpkg/lock-frontend - open (13: Permission denied) E: Unable to acquire the dpkg frontend lock (/var/lib/dpkg/lock-frontend), are you root? zhihui@zhihui-desktop:~/onnx-tensorrt$ sudo su

切換到root用户下就合一避免上面的錯誤

root@zhihui-desktop:/home/zhihui/onnx-tensorrt# sudo apt update -y && apt install -y libprotobuf-dev protobuf-compiler Hit:1 http://ports.ubuntu.com/ubuntu-ports bionic InRelease
Hit:2 http://ports.ubuntu.com/ubuntu-ports bionic-updates InRelease
Hit:3 http://ports.ubuntu.com/ubuntu-ports bionic-backports InRelease
Hit:4 http://ports.ubuntu.com/ubuntu-ports bionic-security InRelease
Hit:5 https://repo.download.nvidia.cn/jetson/common r32.4 InRelease
Hit:6 https://repo.download.nvidia.cn/jetson/t194 r32.4 InRelease Reading package lists... Done
Building dependency tree
Reading state information... Done 6 packages can be upgraded. Run 'apt list --upgradable' to see them. Reading package lists... Done Building dependency tree
Reading state information... Done libprotobuf-dev is already the newest version (3.0.0-9.1ubuntu1). The following packages were automatically installed and are no longer required: activity-log-manager archdetect-deb bamfdaemon bogl-bterm busybox-static compiz-core compiz-plugins-default cryptsetup-bin debhelper dh-autoreconf dh-strip-nondeterminism dpkg-repack gir1.2-accounts-1.0 gir1.2-gdata-0.0 gir1.2-gst-plugins-base-1.0 gir1.2-gstreamer-1.0 gir1.2-harfbuzz-0.0 gir1.2-rb-3.0 gir1.2-signon-1.0 gir1.2-timezonemap-1.0 gir1.2-totem-1.0 gir1.2-totemplparser-1.0 gir1.2-xkl-1.0 gnome-calculator gnome-system-monitor grub-common gtk3-nocsd icu-devtools kde-window-manager kpackagetool5 kwayland-data kwin-common kwin-x11 libarchive-cpio-perl libatkmm-1.6-1v5 libboost-python1.65.1 libcairomm-1.0-1v5 libcolumbus1-common libcolumbus1v5 libcompizconfig0 libdebian-installer4 libdecoration0 libdmapsharing-3.0-2 libegl1-mesa-dev libeigen3-dev libfile-stripnondeterminism-perl libgeonames-common libgeonames0 libgles2-mesa-dev libglibmm-2.4-1v5 libgpod-common libgpod4 libgraphite2-dev libgtk3-nocsd0 libgtkmm-3.0-1v5 libharfbuzz-gobject0 libicu-le-hb0 libiculx60 libkdecorations2-5v5 libkdecorations2private5v5 libkf5activities5 libkf5declarative-data libkf5declarative5 libkf5globalaccelprivate5 libkf5idletime5 libkf5kcmutils-data libkf5kcmutils5 libkf5package-data libkf5package5 libkf5plasma5 libkf5quickaddons5 libkf5waylandclient5 libkf5waylandserver5 libkscreenlocker5 libkwin4-effect-builtins1 libkwineffects11 libkwinglutils11 libkwinxrenderutils11 libmail-sendmail-perl libnm-gtk0 liborc-0.4-dev liborc-0.4-dev-bin libpanel-applet3 libpangomm-1.4-1v5 libpcre16-3 libpcre3-dev libpcre32-3 libpcrecpp0v5 libpinyin-data libpinyin13 libqt5designer5 libqt5help5 libqt5positioning5 libqt5sensors5 libqt5sql5 libqt5test5 libqt5webchannel5 libqt5webkit5 libsgutils2-2 libsignon-glib1 libsys-hostname-long-perl libtimezonemap-data libtimezonemap1 libunity-control-center1 libunity-core-6.0-9 libunity-misc4 libwayland-bin libwayland-dev libxcb-composite0 libxcb-cursor0 libxcb-damage0 libxrandr-dev libxrender-dev libzeitgeist-1.0-1 os-prober pkg-config po-debconf qml-module-org-kde-kquickcontrolsaddons rdate session-shortcuts tasksel tasksel-data unity-asset-pool unity-greeter unity-lens-applications unity-lens-files unity-lens-music unity-lens-video unity-schemas unity-scope-video-remote unity-scopes-master-default unity-scopes-runner x11proto-randr-dev Use 'sudo apt autoremove' to remove them. The following NEW packages will be installed: libprotoc10 protobuf-compiler 0 upgraded, 2 newly installed, 0 to remove and 6 not upgraded. Need to get 556 kB of archives. After this operation, 2348 kB of additional disk space will be used. Get:1 http://ports.ubuntu.com/ubuntu-ports bionic/main arm64 libprotoc10 arm64 3.0.0-9.1ubuntu1 [531 kB] Get:2 http://ports.ubuntu.com/ubuntu-ports bionic/universe arm64 protobuf-compiler arm64 3.0.0-9.1ubuntu1 [24.4 kB] Fetched 556 kB in 2s (259 kB/s)
perl: warning: Setting locale failed. perl: warning: Please check that your locale settings: LANGUAGE = (unset), LC_ALL = (unset), LC_TIME = "zh_CN.UTF-8", LC_MONETARY = "zh_CN.UTF-8", LC_ADDRESS = "zh_CN.UTF-8", LC_TELEPHONE = "zh_CN.UTF-8", LC_NAME = "zh_CN.UTF-8", LC_MEASUREMENT = "zh_CN.UTF-8", LC_IDENTIFICATION = "zh_CN.UTF-8", LC_NUMERIC = "zh_CN.UTF-8", LC_PAPER = "zh_CN.UTF-8", LANG = "en_US.UTF-8" are supported and installed on your system. perl: warning: Falling back to the standard locale ("C"). locale: Cannot set LC_CTYPE to default locale: No such file or directory locale: Cannot set LC_MESSAGES to default locale: No such file or directory locale: Cannot set LC_ALL to default locale: No such file or directory Selecting previously unselected package libprotoc10:arm64. (Reading database ... 164315 files and directories currently installed.) Preparing to unpack .../libprotoc10_3.0.0-9.1ubuntu1_arm64.deb ... Unpacking libprotoc10:arm64 (3.0.0-9.1ubuntu1) ... Selecting previously unselected package protobuf-compiler. Preparing to unpack .../protobuf-compiler_3.0.0-9.1ubuntu1_arm64.deb ... Unpacking protobuf-compiler (3.0.0-9.1ubuntu1) ... Setting up libprotoc10:arm64 (3.0.0-9.1ubuntu1) ... Setting up protobuf-compiler (3.0.0-9.1ubuntu1) ... Processing triggers for man-db (2.8.3-2ubuntu0.1) ... Processing triggers for libc-bin (2.27-3ubuntu1.2) ... root@zhihui-desktop:/home/zhihui/onnx-tensorrt# sudo su zhihui ```

注意:

你可能會遇到上面的錯誤E: Could not open lock file /var/lib/dpkg/lock-frontend - open (13: Permission denied),解決方法;

  • 方法一:切換到root用户下:sudo su
  • 方法二:刪除文件:sudo rm -rf /var/lib/dpkg/lock-frontend

leader教我的,其實可以用apt-get安裝protobuf的

先使用下面的命令查看protobuf相關的名字的庫包,因為我們並不知道在apt的庫中它叫什麼名字:

apt-cache search protobuf

5、執行cmake,命令如下:

mkdir build && cd build cmake .. -DTENSORRT_ROOT=/usr/src/tensorrt -DCUDA_INCLUDE_DIRS=/usr/local/cuda/include

cmake結果顯示

```python root@zhihui-desktop:/home/zhihui/onnx-tensorrt# sudo su zhihui zhihui@zhihui-desktop:~/onnx-tensorrt$ mkdir build && cd build zhihui@zhihui-desktop:~/onnx-tensorrt/build$ cmake .. -DTENSORRT_ROOT=/usr/src/tensorrt -DCUDA_INCLUDE_DIRS=/usr/local/cuda/include -- The CXX compiler identification is GNU 7.5.0 -- The C compiler identification is GNU 7.5.0 -- Detecting CXX compiler ABI info -- Detecting CXX compiler ABI info - done -- Check for working CXX compiler: /usr/bin/c++ - skipped -- Detecting CXX compile features -- Detecting CXX compile features - done -- Detecting C compiler ABI info -- Detecting C compiler ABI info - done -- Check for working C compiler: /usr/bin/cc - skipped -- Detecting C compile features -- Detecting C compile features - done -- Found Protobuf: /usr/local/lib/libprotobuf.so;-lpthread (found version "3.8.0") -- Build type not set - defaulting to Release Generated: /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx_onnx2trt_onnx-ml.proto Generated: /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx-operators_onnx2trt_onnx-ml.proto -- -- * Summary * -- CMake version : 3.18.2 -- CMake command : /usr/local/bin/cmake -- System : Linux -- C++ compiler : /usr/bin/c++ -- C++ compiler version : 7.5.0 -- CXX flags : -Wall -Wno-deprecated-declarations -Wno-unused-function -Wnon-virtual-dtor -- Build type : Release -- Compile definitions : ONNX_NAMESPACE=onnx2trt_onnx -- CMAKE_PREFIX_PATH : -- CMAKE_INSTALL_PREFIX : /usr/local -- CMAKE_MODULE_PATH : -- -- ONNX version : 1.6.0 -- ONNX NAMESPACE : onnx2trt_onnx -- ONNX_BUILD_TESTS : OFF -- ONNX_BUILD_BENCHMARKS : OFF -- ONNX_USE_LITE_PROTO : OFF -- ONNXIFI_DUMMY_BACKEND : OFF -- ONNXIFI_ENABLE_EXT : OFF -- -- Protobuf compiler : /usr/local/bin/protoc -- Protobuf includes : /usr/local/include -- Protobuf libraries : /usr/local/lib/libprotobuf.so;-lpthread -- BUILD_ONNX_PYTHON : OFF -- Found TensorRT headers at /usr/include/aarch64-linux-gnu -- Find TensorRT libs at /usr/lib/aarch64-linux-gnu/libnvinfer.so;/usr/lib/aarch64-linux-gnu/libnvinfer_plugin.so;/usr/lib/aarch64-linux-gnu/libmyelin.so -- Found TENSORRT: /usr/include/aarch64-linux-gnu
-- Configuring done -- Generating done CMake Warning: Manually-specified variables were not used by the project:

CUDA_INCLUDE_DIRS

-- Build files have been written to: /home/zhihui/onnx-tensorrt/build

```

注意:

如下,可能會出現cmake版本過對的情況! ```python (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints/onnx-tensorrt/build$ cmake .. -DTENSORRT_ROOT=../tensorrt_root && make -j CMake Error at CMakeLists.txt:21 (cmake_minimum_required): CMake 3.13 or higher is required. You are running version 3.10.2

-- Configuring incomplete, errors occurred! (yolov4) shl@zhihui-mint:~/shl_res/1_project/yolov4-deepsort/checkpoints/onnx-tensorrt/build$ ```

上面顯示我們的cmake版本過低,需要更新cmake的版本,如何更新cmake的版本,請參考這篇博客

6、編譯:build

make -j8

編譯的結果顯示如下:

python zhihui@zhihui-desktop:~/onnx-tensorrt/build$ make -j8 Scanning dependencies of target gen_onnx_proto [ 1%] Running gen_proto.py on onnx/onnx.in.proto Processing /home/zhihui/onnx-tensorrt/third_party/onnx/onnx/onnx.in.proto Writing /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx_onnx2trt_onnx-ml.proto Writing /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx_onnx2trt_onnx-ml.proto3 Writing /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx-ml.pb.h generating /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx_pb.py [ 2%] Running C++ protocol buffer compiler on /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx_onnx2trt_onnx-ml.proto [ 2%] Built target gen_onnx_proto [ 3%] Running gen_proto.py on onnx/onnx-operators.in.proto Processing /home/zhihui/onnx-tensorrt/third_party/onnx/onnx/onnx-operators.in.proto Writing /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx-operators_onnx2trt_onnx-ml.proto Writing /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx-operators_onnx2trt_onnx-ml.proto3 Writing /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx-operators-ml.pb.h generating /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx_operators_pb.py [ 5%] Running C++ protocol buffer compiler on /home/zhihui/onnx-tensorrt/build/third_party/onnx/onnx/onnx-operators_onnx2trt_onnx-ml.proto Scanning dependencies of target onnx_proto [ 6%] Building CXX object third_party/onnx/CMakeFiles/onnx_proto.dir/onnx/onnx_onnx2trt_onnx-ml.pb.cc.o [ 7%] Building CXX object third_party/onnx/CMakeFiles/onnx_proto.dir/onnx/onnx-operators_onnx2trt_onnx-ml.pb.cc.o [ 8%] Linking CXX static library libonnx_proto.a [ 11%] Built target onnx_proto Scanning dependencies of target nvonnxparser_static Scanning dependencies of target nvonnxparser Scanning dependencies of target onnx [ 12%] Building CXX object CMakeFiles/nvonnxparser_static.dir/NvOnnxParser.cpp.o [ 15%] Building CXX object CMakeFiles/nvonnxparser_static.dir/ModelImporter.cpp.o [ 14%] Building CXX object CMakeFiles/nvonnxparser_static.dir/builtin_op_importers.cpp.o [ 16%] Building CXX object CMakeFiles/nvonnxparser.dir/ModelImporter.cpp.o [ 17%] Building CXX object CMakeFiles/nvonnxparser_static.dir/onnx2trt_utils.cpp.o [ 19%] Building CXX object CMakeFiles/nvonnxparser.dir/NvOnnxParser.cpp.o [ 20%] Building CXX object CMakeFiles/nvonnxparser.dir/builtin_op_importers.cpp.o [ 21%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/checker.cc.o [ 23%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/common/assertions.cc.o [ 24%] Building CXX object CMakeFiles/nvonnxparser_static.dir/ShapedWeights.cpp.o [ 25%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/common/interned_strings.cc.o [ 26%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/common/ir_pb_converter.cc.o [ 28%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/common/model_helpers.cc.o [ 29%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/common/status.cc.o [ 30%] Building CXX object CMakeFiles/nvonnxparser_static.dir/ShapeTensor.cpp.o [ 32%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/attr_proto_util.cc.o [ 33%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/controlflow/defs.cc.o [ 34%] Building CXX object CMakeFiles/nvonnxparser.dir/onnx2trt_utils.cpp.o [ 35%] Building CXX object CMakeFiles/nvonnxparser_static.dir/LoopHelpers.cpp.o [ 37%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/controlflow/old.cc.o [ 38%] Building CXX object CMakeFiles/nvonnxparser_static.dir/RNNHelpers.cpp.o [ 39%] Building CXX object CMakeFiles/nvonnxparser_static.dir/OnnxAttrs.cpp.o [ 41%] Building CXX object CMakeFiles/nvonnxparser.dir/ShapedWeights.cpp.o [ 42%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/data_type_utils.cc.o [ 43%] Building CXX object CMakeFiles/nvonnxparser.dir/ShapeTensor.cpp.o [ 44%] Building CXX object CMakeFiles/nvonnxparser.dir/LoopHelpers.cpp.o [ 46%] Building CXX object CMakeFiles/nvonnxparser.dir/RNNHelpers.cpp.o [ 47%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/function.cc.o [ 48%] Building CXX object CMakeFiles/nvonnxparser.dir/OnnxAttrs.cpp.o [ 50%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/generator/defs.cc.o [ 51%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/generator/old.cc.o [ 52%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/logical/defs.cc.o [ 53%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/logical/old.cc.o [ 55%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/math/defs.cc.o [ 56%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/math/old.cc.o [ 57%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/nn/defs.cc.o [ 58%] Linking CXX static library libnvonnxparser_static.a [ 58%] Built target nvonnxparser_static Scanning dependencies of target getSupportedAPITest [ 60%] Building CXX object CMakeFiles/getSupportedAPITest.dir/getSupportedAPITest.cpp.o [ 61%] Building CXX object CMakeFiles/getSupportedAPITest.dir/ModelImporter.cpp.o [ 62%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/nn/old.cc.o [ 64%] Linking CXX shared library libnvonnxparser.so [ 65%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/object_detection/defs.cc.o [ 65%] Built target nvonnxparser [ 66%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/object_detection/old.cc.o [ 67%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/quantization/defs.cc.o [ 69%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/reduction/defs.cc.o [ 70%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/reduction/old.cc.o [ 71%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/rnn/defs.cc.o [ 73%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/rnn/old.cc.o [ 74%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/schema.cc.o [ 75%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/sequence/defs.cc.o [ 76%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/tensor/defs.cc.o [ 78%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/tensor/old.cc.o [ 79%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/tensor/utils.cc.o [ 80%] Linking CXX executable getSupportedAPITest [ 82%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/tensor_proto_util.cc.o [ 82%] Built target getSupportedAPITest [ 83%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/tensor_util.cc.o [ 84%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/traditionalml/defs.cc.o [ 85%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/defs/traditionalml/old.cc.o [ 87%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/onnxifi_utils.cc.o [ 88%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/optimizer/optimize.cc.o [ 89%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/optimizer/pass.cc.o [ 91%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/optimizer/pass_manager.cc.o [ 92%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/optimizer/pass_registry.cc.o [ 93%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/shape_inference/implementation.cc.o [ 94%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/version_converter/convert.cc.o [ 96%] Building CXX object third_party/onnx/CMakeFiles/onnx.dir/onnx/version_converter/helper.cc.o [ 97%] Linking CXX static library libonnx.a [ 97%] Built target onnx Scanning dependencies of target onnx2trt [ 98%] Building CXX object CMakeFiles/onnx2trt.dir/main.cpp.o [100%] Linking CXX executable onnx2trt [100%] Built target onnx2trt

編譯後可以在build目錄下查看到如下文件

python zhihui@zhihui-desktop:~/onnx-tensorrt/build$ ls CMakeCache.txt cmake_install.cmake libnvonnxparser_static.a CMakeFiles getSupportedAPITest onnx2trt CPackConfig.cmake libnvonnxparser.so third_party CPackSourceConfig.cmake libnvonnxparser.so.7 Makefile libnvonnxparser.so.7.1.0

7、查看編譯生成的onnx2trt可執行文件,是否能用

python zhihui@zhihui-desktop:~/onnx-tensorrt/build$ ./onnx2trt ONNX to TensorRT model parser Usage: onnx2trt onnx_model.pb [-o engine_file.trt] (output TensorRT engine) [-t onnx_model.pbtxt] (output ONNX text file without weights) [-T onnx_model.pbtxt] (output ONNX text file with weights) [-m onnx_model_out.pb] (output ONNX model) [-b max_batch_size (default 32)] [-w max_workspace_size_bytes (default 1 GiB)] [-d model_data_type_bit_depth] (32 => float32, 16 => float16) [-O passes] (optimize onnx model. Argument is a semicolon-separated list of passes) [-p] (list available optimization passes and exit) [-l] (list layers and their shapes) [-g] (debug mode) [-F] (optimize onnx model in fixed mode) [-v] (increase verbosity) [-q] (decrease verbosity) [-V] (show version information) [-h] (show help) zhihui@zhihui-desktop:~/onnx-tensorrt/build$

2.2 使用onnx2trt工具把我們的onnx模型轉換為trt模型

使用onnx2trt把onnx模型轉換成trt模型,命令如下:

./onnx2trt ~/yolov4-deepsort/checkpoints/yolov4-tiny-416.onnx -o ~/yolov4-deepsort/checkpoints/saved_model_engine.trt

我轉換的過程中遇到問題:ERROR] INVALID_ARGUMENT: getPluginCreator could not find plugin NonZero,這問題最終我是沒有解決

```python zhihui@zhihui-desktop:~/onnx-tensorrt/build$ ./onnx2trt ~/yolov4-deepsort/checkpoints/yolov4-tiny-416.onnx -o ~/yolov4-deepsort/checkpoints/saved_model_engine.trt


Input filename: /home/zhihui/yolov4-deepsort/checkpoints/yolov4-tiny-416.onnx ONNX IR version: 0.0.5 Opset version: 10 Producer name: tf2onnx Producer version: 1.8.0 Domain:
Model version: 0 Doc string:


Parsing model [2020-10-28 07:27:28 WARNING] [TRT]/home/zhihui/onnx-tensorrt/onnx2trt_utils.cpp:220: Your ONNX model has been generated with INT64 weights, while TensorRT does not natively support INT64. Attempting to cast down to INT32. [2020-10-28 07:27:28 ERROR] INVALID_ARGUMENT: getPluginCreator could not find plugin NonZero version 1 While parsing node number 128 [NonZero -> "StatefulPartitionedCall/functional_1/tf_op_layer_Where/Where:0"]: ERROR: /home/zhihui/onnx-tensorrt/builtin_op_importers.cpp:3750 In function importFallbackPluginImporter: [8] Assertion failed: creator && "Plugin not found, are the plugin name, version, and namespace correct?" zhihui@zhihui-desktop:~/onnx-tensorrt/build$

```

使用tensorrt的trtexec工具轉換也是報同樣的錯誤:INVALID_ARGUMENT: getPluginCreator could not find plugin NonZero version 1

```python zhihui@zhihui-desktop:/usr/src/tensorrt/bin$ ./trtexec --onnx=/home/zhihui/yolov4-deepsort/checkpoints/saved_model.onnx --explicitBatch --saveEngine=/home/zhihui/yolov4-deepsort/checkpoints/saved_model.trt --fp16 &&&& RUNNING TensorRT.trtexec # ./trtexec --onnx=/home/zhihui/yolov4-deepsort/checkpoints/saved_model.onnx --explicitBatch --saveEngine=/home/zhihui/yolov4-deepsort/checkpoints/saved_model.trt --fp16 [10/28/2020-11:23:25] [I] === Model Options === [10/28/2020-11:23:25] [I] Format: ONNX [10/28/2020-11:23:25] [I] Model: /home/zhihui/yolov4-deepsort/checkpoints/saved_model.onnx [10/28/2020-11:23:25] [I] Output: [10/28/2020-11:23:25] [I] === Build Options === [10/28/2020-11:23:25] [I] Max batch: explicit [10/28/2020-11:23:25] [I] Workspace: 16 MB [10/28/2020-11:23:25] [I] minTiming: 1 [10/28/2020-11:23:25] [I] avgTiming: 8 [10/28/2020-11:23:25] [I] Precision: FP32+FP16 [10/28/2020-11:23:25] [I] Calibration: [10/28/2020-11:23:25] [I] Safe mode: Disabled [10/28/2020-11:23:25] [I] Save engine: /home/zhihui/yolov4-deepsort/checkpoints/saved_model.trt [10/28/2020-11:23:25] [I] Load engine: [10/28/2020-11:23:25] [I] Builder Cache: Enabled [10/28/2020-11:23:25] [I] NVTX verbosity: 0 [10/28/2020-11:23:25] [I] Inputs format: fp32:CHW [10/28/2020-11:23:25] [I] Outputs format: fp32:CHW [10/28/2020-11:23:25] [I] Input build shapes: model [10/28/2020-11:23:25] [I] Input calibration shapes: model [10/28/2020-11:23:25] [I] === System Options === [10/28/2020-11:23:25] [I] Device: 0 [10/28/2020-11:23:25] [I] DLACore: [10/28/2020-11:23:25] [I] Plugins: [10/28/2020-11:23:25] [I] === Inference Options === [10/28/2020-11:23:25] [I] Batch: Explicit [10/28/2020-11:23:25] [I] Input inference shapes: model [10/28/2020-11:23:25] [I] Iterations: 10 [10/28/2020-11:23:25] [I] Duration: 3s (+ 200ms warm up) [10/28/2020-11:23:25] [I] Sleep time: 0ms [10/28/2020-11:23:25] [I] Streams: 1 [10/28/2020-11:23:25] [I] ExposeDMA: Disabled [10/28/2020-11:23:25] [I] Spin-wait: Disabled [10/28/2020-11:23:25] [I] Multithreading: Disabled [10/28/2020-11:23:25] [I] CUDA Graph: Disabled [10/28/2020-11:23:25] [I] Skip inference: Disabled [10/28/2020-11:23:25] [I] Inputs: [10/28/2020-11:23:25] [I] === Reporting Options === [10/28/2020-11:23:25] [I] Verbose: Disabled [10/28/2020-11:23:25] [I] Averages: 10 inferences [10/28/2020-11:23:25] [I] Percentile: 99 [10/28/2020-11:23:25] [I] Dump output: Disabled [10/28/2020-11:23:25] [I] Profile: Disabled [10/28/2020-11:23:25] [I] Export timing to JSON file: [10/28/2020-11:23:25] [I] Export output to JSON file: [10/28/2020-11:23:25] [I] Export profile to JSON file: [10/28/2020-11:23:25] [I]


Input filename: /home/zhihui/yolov4-deepsort/checkpoints/saved_model.onnx ONNX IR version: 0.0.5 Opset version: 10 Producer name: tf2onnx Producer version: 1.7.1 Domain:
Model version: 0 Doc string:


[10/28/2020-11:23:29] [W] [TRT] onnx2trt_utils.cpp:220: Your ONNX model has been generated with INT64 weights, while TensorRT does not natively support INT64. Attempting to cast down to INT32. [10/28/2020-11:23:29] [I] [TRT] ModelImporter.cpp:135: No importer registered for op: NonZero. Attempting to import as plugin. [10/28/2020-11:23:29] [I] [TRT] builtin_op_importers.cpp:3659: Searching for plugin: NonZero, plugin_version: 1, plugin_namespace: [10/28/2020-11:23:29] [E] [TRT] INVALID_ARGUMENT: getPluginCreator could not find plugin NonZero version 1 ERROR: builtin_op_importers.cpp:3661 In function importFallbackPluginImporter: [8] Assertion failed: creator && "Plugin not found, are the plugin name, version, and namespace correct?" [10/28/2020-11:23:29] [E] Failed to parse onnx file [10/28/2020-11:23:29] [E] Parsing model failed [10/28/2020-11:23:29] [E] Engine creation failed [10/28/2020-11:23:29] [E] Engine set up failed &&&& FAILED TensorRT.trtexec # ./trtexec --onnx=/home/zhihui/yolov4-deepsort/checkpoints/saved_model.onnx --explicitBatch --saveEngine=/home/zhihui/yolov4-deepsort/checkpoints/saved_model.trt --fp16 zhihui@zhihui-desktop:/usr/src/tensorrt/bin$ ```
