ElasticSearch必知必會-進階篇

語言: CN / TW / HK

京東物流:康睿 姚再毅 李振 劉斌 王北永

說明:以下全部均基於 ElasticSearch 8.1 版本

一.跨叢集檢索 - ccr

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/modules-cross-cluster-search.html

跨叢集檢索的背景和意義

跨叢集檢索定義

跨叢集檢索環境搭建

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/modules-cross-cluster-search.html

步驟1:搭建兩個本地單節點叢集,本地練習可取消安全配置

步驟2:每個叢集都執行以下命令

PUT _cluster/settings { "persistent": { "cluster": { "remote": { "cluster_one": { "seeds": [ "172.21.0.14:9301" ] },"cluster_two": { "seeds": [ "172.21.0.14:9302" ] } } } } }

步驟3:驗證叢集之間是否互通

方案1:Kibana 視覺化檢視:stack Management -> Remote Clusters -> status 應該是 connected! 且必須打上綠色的對號。

​ 方案2:GET _remote/info

跨叢集查詢演練

# 步驟1 在叢集 1 中新增資料如下
PUT test01/_bulk
{"index":{"_id":1}}
{"title":"this is from cluster01..."}

# 步驟2 在叢集 2 中新增資料如下:
PUT test01/_bulk
{"index":{"_id":1}}
{"title":"this is from cluster02..."}

# 步驟 3:執行跨叢集檢索如下: 語法:POST 叢集名稱1:索引名稱,叢集名稱2:索引名稱/_search
POST cluster_one:test01,cluster_two:test01/_search
{
  "took" : 7,
  "timed_out" : false,
  "num_reduce_phases" : 3,
  "_shards" : {
    "total" : 2,
    "successful" : 2,
    "skipped" : 0,
    "failed" : 0
  },
  "_clusters" : {
    "total" : 2,
    "successful" : 2,
    "skipped" : 0
  },
  "hits" : {
    "total" : {
      "value" : 2,
      "relation" : "eq"
    },
    "max_score" : 1.0,
    "hits" : [
      {
        "_index" : "cluster_two:test01",
        "_id" : "1",
        "_score" : 1.0,
        "_source" : {
          "title" : "this is from cluster02..."
        }
      },
      {
        "_index" : "cluster_one:test01",
        "_id" : "1",
        "_score" : 1.0,
        "_source" : {
          "title" : "this is from cluster01..."
        }
      }
    ]
  }
}



二.跨叢集複製 - ccs - 該功能需付費

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/current/xpack-ccr.html

如何保障叢集的高可用

  1. 副本機制
  2. 快照和恢復
  3. 跨叢集複製(類似mysql 主從同步)

跨叢集複製概述

跨叢集複製配置

  1. 準備兩個叢集,網路互通
  2. 開啟 license 使用,可試用30天
  • 開啟位置:Stack Management -> License mangement.

3.定義好誰是Leads叢集,誰是follower叢集

4.在follower叢集配置Leader叢集

5.在follower叢集配置Leader叢集的索引同步規則(kibana頁面配置)

a.stack Management -> Cross Cluster Replication -> create a follower index.

6.啟用步驟5的配置


三索引模板

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/index-templates.html

8.X之元件模板

1.建立元件模板-索引setting相關

# 元件模板 - 索引setting相關
PUT _component_template/template_sttting_part
{
  "template": {
    "settings": {
      "number_of_shards": 3,
      "number_of_replicas": 0
    }
  }
}


2.建立元件模板-索引mapping相關

# 元件模板 - 索引mapping相關
PUT _component_template/template_mapping_part
{
  "template": {
    "mappings": {
      "properties": {
        "hosr_name":{
          "type": "keyword"
        },
        "cratet_at":{
          "type": "date",
          "format": "EEE MMM dd HH:mm:ss Z yyyy"
        }
      }
    }
  }
}


3.建立元件模板-配置模板和索引之間的關聯

// **注意:composed_of 如果多個元件模板中的配置項有重複,後面的會覆蓋前面的,和配置的順序有關**
# 基於元件模板,配置模板和索引之間的關聯
# 也就是所有 tem_* 該表示式相關的索引建立時,都會使用到以下規則
PUT _index_template/template_1
{
  "index_patterns": [
    "tem_*"
  ],
  "composed_of": [
    "template_sttting_part",
    "template_mapping_part"
  ]
}


4.測試

# 建立測試
PUT tem_001


索引模板基本操作

實戰演練

需求1:預設如果不顯式指定Mapping,數值型別會被動態對映為long型別,但實際上業務數值都比較小,會存在儲存浪費。需要將預設值指定為Integer

索引模板,官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/index-templates.html

mapping-動態模板,官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/dynamic-templates.html

# 結合mapping 動態模板 和 索引模板
# 1.建立元件模板之 - mapping模板
PUT _component_template/template_mapping_part_01
{
  "template": {
    "mappings": {
      "dynamic_templates": [
        {
          "integers": {
            "match_mapping_type": "long",
            "mapping": {
              "type": "integer"
            }
          }
        }
      ]
    }
  }
}

# 2. 建立元件模板與索引關聯配置
PUT _index_template/template_2
{
  "index_patterns": ["tem1_*"],
  "composed_of": ["template_mapping_part_01"]
}

# 3.建立測試資料
POST tem1_001/_doc/1
{
  "age":18
}

# 4.檢視mapping結構驗證
get tem1_001/_mapping



需求2:date_*開頭的欄位,統一匹配為date日期型別。

索引模板,官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/index-templates.html

mapping-動態模板,官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/dynamic-templates.html

# 結合mapping 動態模板 和 索引模板
# 1.建立元件模板之 - mapping模板
PUT _component_template/template_mapping_part_01
{
  "template": {
    "mappings": {
      "dynamic_templates": [
        {
          "integers": {
            "match_mapping_type": "long",
            "mapping": {
              "type": "integer"
            }
          }
        },
        {
        "date_type_process": {
          "match": "date_*",
          "mapping": {
            "type": "date",
            "format":"yyyy-MM-dd HH:mm:ss"
          }
        }
      }
      ]
    }
  }
}

# 2. 建立元件模板與索引關聯配置
PUT _index_template/template_2
{
  "index_patterns": ["tem1_*"],
  "composed_of": ["template_mapping_part_01"]
}


# 3.建立測試資料
POST tem1_001/_doc/2
{
  "age":19,
  "date_aoe":"2022-01-01 18:18:00"
}

# 4.檢視mapping結構驗證
get tem1_001/_mapping


四.LIM 索引生命週期管理

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/index-lifecycle-management.html

什麼是索引生命週期

索引的 生-> 老 -> 病 -> 死

是否有過考慮,如果一個索引,建立之後,就不再去管理了?會發生什麼?

什麼是索引生命週期管理

索引太大了會如何?

大索引的恢復時間,要遠比小索引恢復慢的多的多索引大了以後,檢索會很慢,寫入和更新也會受到不同程度的影響索引大到一定程度,當索引出現健康問題,會導致整個叢集核心業務不可用

最佳實踐

叢集的單個分片最大文件數上限:2的32次冪減1,即20億左右官方建議:分片大小控制在30GB-50GB,若索引資料量無限增大,肯定會超過這個值

使用者不關注全量

某些業務場景,業務更關注近期的資料,如近3天、近7天大索引會將全部歷史資料彙集在一起,不利於這種場景的查詢

索引生命週期管理的歷史演變

LIM前奏 - rollover 滾動索引

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/index-rollover.html

# 0.自測前提,lim生命週期rollover頻率。預設10分鐘
PUT _cluster/settings
{
  "persistent": {
    "indices.lifecycle.poll_interval": "1s"
  }
}

# 1. 建立索引,並指定別名
PUT test_index-0001
{
  "aliases": {
    "my-test-index-alias": {
      "is_write_index": true
    }
  }
}

# 2.批量匯入資料
PUT my-test-index-alias/_bulk
{"index":{"_id":1}}
{"title":"testing 01"}
{"index":{"_id":2}}
{"title":"testing 02"}
{"index":{"_id":3}}
{"title":"testing 03"}
{"index":{"_id":4}}
{"title":"testing 04"}
{"index":{"_id":5}}
{"title":"testing 05"}

# 3.rollover 滾動規則配置
POST my-test-index-alias/_rollover
{
  "conditions": {
    "max_age": "7d",
    "max_docs": 5,
    "max_primary_shard_size": "50gb"
  }
}

# 4.在滿足條件的前提下建立滾動索引
PUT my-test-index-alias/_bulk
{"index":{"_id":7}}
{"title":"testing 07"}

# 5.查詢驗證滾動是否成功
POST my-test-index-alias/_search


LIM前奏 - shrink 索引壓縮

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/ilm-shrink.html

核心步驟:

1. 將資料全部遷移至一個獨立的節點

2. 索引禁止寫入

3. 方可進行壓縮

# 1.準備測試資料
DELETE kibana_sample_data_logs_ext
PUT kibana_sample_data_logs_ext
{
  "settings": {
    "number_of_shards": 5,
    "number_of_replicas": 0
  }
}
POST _reindex
{
  "source": {
    "index": "kibana_sample_data_logs"
  },
  "dest": {
    "index": "kibana_sample_data_logs_ext"
  }
}


# 2.壓縮前必要的條件設定
# number_of_replicas :壓縮後副本為0
# index.routing.allocation.include._tier_preference 資料分片全部路由到hot節點
# "index.blocks.write 壓縮後索引不再允許資料寫入
PUT kibana_sample_data_logs_ext/_settings
{
  "settings": {
    "index.number_of_replicas": 0,
    "index.routing.allocation.include._tier_preference": "data_hot",
    "index.blocks.write": true
  }
}

# 3.實施壓縮
POST kibana_sample_data_logs_ext/_shrink/kibana_sample_data_logs_ext_shrink
{
  "settings":{
    "index.number_of_replicas": 0,
    "index.number_of_shards": 1,
    "index.codec":"best_compression"
  },
  "aliases":{
    "kibana_sample_data_logs_alias":{}
  }
}


LIM實戰

全域性認知建立 - 四大階段

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/overview-index-lifecycle-management.html

生命週期管理階段(Policy):
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/ilm-index-lifecycle.html

Hot階段(生)

Set priority

Unfollow

Rollover

Read-only

Shrink

Force Merge

Search snapshot

Warm階段(老)

Set priority

Unfollow

Read-only

Allocate

migrate

Shirink

Force Merge

Cold階段(病)

Search snapshot

Delete階段(死)

delete

演練

1.建立policy

  • Hot階段設定,rollover: max_age:3d,max_docs:5, max_size:50gb, 優先順序:100

  • Warm階段設定:min_age:15s , forcemerage段合併,熱節點遷移到warm節點,副本數設定0,優先順序:50

  • Cold階段設定: min_age 30s, warm遷移到cold階段

  • Delete階段設定:min_age 45s,執行刪除操作

PUT _ilm/policy/kr_20221114_policy
{
  "policy": {
    "phases": {
      "hot": {
        "min_age": "0ms",
        "actions": {
          "set_priority": {
            "priority": 100
          },
          "rollover": {
            "max_size": "50gb",
            "max_primary_shard_size": "50gb",
            "max_age": "3d",
            "max_docs": 5
          }
        }
      },
      "warm": {
        "min_age": "15s",
        "actions": {
          "forcemerge": {
            "max_num_segments": 1
          },
          "set_priority": {
            "priority": 50
          },
          "allocate": {
            "number_of_replicas": 0
          }
        }
      },
      "cold": {
        "min_age": "30s",
        "actions": {
          "set_priority": {
            "priority": 0
          }
        }
      },
      "delete": {
        "min_age": "45s",
        "actions": {
          "delete": {
            "delete_searchable_snapshot": true
          }
        }
      }
    }
  }
}


2.建立index template

PUT _index_template/kr_20221114_template
{
  "index_patterns": ["kr_index-**"],
  "template": {
    "settings": {
      "index": {
        "lifecycle": {
          "name": "kr_20221114_policy",
          "rollover_alias": "kr-index-alias"
        },
        "routing": {
          "allocation": {
            "include": {
              "_tier_preference": "data-hot"
            }
          }
        },
        "number_of_shards": "3",
        "number_of_replicas": "1"
      }
    },
    "aliases": {},
    "mappings": {}
  }
}



3.測試需要修改lim rollover重新整理頻率

PUT _cluster/settings
{
  "persistent": {
    "indices.lifecycle.poll_interval": "1s"
  }
}


4.進行測試

# 建立索引,並制定可寫別名
PUT kr_index-0001
{
  "aliases": {
    "kr-index-alias": {
      "is_write_index": true
    }
  }
}
# 通過別名新增資料
PUT kr-index-alias/_bulk
{"index":{"_id":1}}
{"title":"testing 01"}
{"index":{"_id":2}}
{"title":"testing 02"}
{"index":{"_id":3}}
{"title":"testing 03"}
{"index":{"_id":4}}
{"title":"testing 04"}
{"index":{"_id":5}}
{"title":"testing 05"}
# 通過別名新增資料,觸發rollover
PUT kr-index-alias/_bulk
{"index":{"_id":6}}
{"title":"testing 06"}
# 檢視索引情況
GET kr_index-0001

get _cat/indices?v


過程總結

第一步:配置 lim pollicy

  • 橫向:Phrase 階段(Hot、Warm、Cold、Delete) 生老病死

  • 縱向:Action 操作(rollover、forcemerge、readlyonly、delete)

第二步:建立模板 繫結policy,指定別名

第三步:建立起始索引

第四步:索引基於第一步指定的policy進行滾動


五.Data Stream

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/ilm-actions.html

特性解析

Data Stream讓我們跨多個索引儲存時序資料,同時給了唯一的對外介面(data stream名稱)

  • 寫入和檢索請求發給data stream

  • data stream將這些請求路由至 backing index(後臺索引)

Backing indices

每個data stream由多個隱藏的後臺索引構成

  • 自動建立

  • 要求模板索引

rollover 滾動索引機制用於自動生成後臺索引

  • 將成為data stream 新的寫入索引

應用場景

  1. 日誌、事件、指標等其他持續建立(少更新)的業務資料
  2. 兩大核心特點
  3. 時序性資料
  4. 資料極少更新或沒有更新

建立Data Stream 核心步驟

官網文件地址:
https://www.elastic.co/guide/en/elasticsearch/reference/8.1/set-up-a-data-stream.html

Set up a data stream

To set up a data stream, follow these steps:

  1. Create an index lifecycle policy
  2. Create component templates
  3. Create an index template
  4. Create the data stream
  5. Secure the data stream

演練

1. 建立一個data stream,名稱為my-data-stream

2. index_template 名稱為 my-index-template

3. 滿足index格式【"my-data-stream*"】的索引都要被應用到

4. 資料插入的時候,在data_hot節點

5. 過3分鐘之後要rollover到data_warm節點

6. 再過5分鐘要到data_cold節點

# 步驟1 。建立 lim policy
PUT _ilm/policy/my-lifecycle-policy
{
  "policy": {
    "phases": {
      "hot": {
        "actions": {
          "rollover": {
            "max_size": "50gb",
            "max_age": "3m",
            "max_docs": 5
          },
          "set_priority": {
            "priority": 100
          }
        }
      },
      "warm": {
        "min_age": "5m",
        "actions": {
          "allocate": {
            "number_of_replicas": 0
          },
          "forcemerge": {
            "max_num_segments": 1
          },
          "set_priority": {
            "priority": 50
          }
        }
      },
      "cold": {
        "min_age": "6m",
        "actions": {
          "freeze":{}
        }
      },
      "delete": {
        "min_age": "45s",
        "actions": {
          "delete": {}
        }
      }
    }
  }
}

# 步驟2 建立元件模板 - mapping
PUT _component_template/my-mappings
{
  "template": {
    "mappings": {
      "properties": {
        "@timestamp": {
          "type": "date",
          "format": "date_optional_time||epoch_millis"
        },
        "message": {
          "type": "wildcard"
        }
      }
    }
  },
  "_meta": {
    "description": "Mappings for @timestamp and message fields",
    "my-custom-meta-field": "More arbitrary metadata"
  }
}

# 步驟3 建立元件模板 - setting
PUT _component_template/my-settings
{
  "template": {
    "settings": {
      "index.lifecycle.name": "my-lifecycle-policy",
      "index.routing.allocation.include._tier_preference":"data_hot"
    }
  },
  "_meta": {
    "description": "Settings for ILM",
    "my-custom-meta-field": "More arbitrary metadata"
  }
}

# 步驟4 建立索引模板
PUT _index_template/my-index-template
{
  "index_patterns": ["my-data-stream*"],
  "data_stream": { },
  "composed_of": [ "my-mappings", "my-settings" ],
  "priority": 500,
  "_meta": {
    "description": "Template for my time series data",
    "my-custom-meta-field": "More arbitrary metadata"
  }
}

# 步驟5 建立 data stream  並 寫入資料測試
PUT my-data-stream/_bulk
{ "create":{ } }
{ "@timestamp": "2099-05-06T16:21:15.000Z", "message": "192.0.2.42 - - [06/May/2099:16:21:15 +0000] \"GET /images/bg.jpg HTTP/1.0\" 200 24736" }
{ "create":{ } }
{ "@timestamp": "2099-05-06T16:25:42.000Z", "message": "192.0.2.255 - - [06/May/2099:16:25:42 +0000] \"GET /favicon.ico HTTP/1.0\" 200 3638" }

POST my-data-stream/_doc
{
  "@timestamp": "2099-05-06T16:21:15.000Z",
  "message": "192.0.2.42 - - [06/May/2099:16:21:15 +0000] \"GET /images/bg.jpg HTTP/1.0\" 200 24736"
}


# 步驟6 檢視data stream 後臺索引資訊
GET /_resolve/index/my-data-stream*
