一文吃透Spring Boot擴充套件之BeanFactoryPostProcessor

語言: CN / TW / HK

概述

BeanFactoryPostProcessor是Spring中一個相當重要的擴充套件點,擴充套件點就是能讓我們在Spring容器以及Bean生命週期的各個階段中可以進行修改擴充套件。

什麼是BeanFactoryPostProcessor

BeanFactoryPostProcessor, 翻譯過來大致是Bean的工廠處理器,顧名思義,可以理解為它對Bean工廠中Bean定義(BeanDefintion)進行修改, 它的執行時機:BeanFactory標準初始化之後,所有的Bean定義已經被載入,但標準Bean的例項還沒被建立(不包括BeanFactoryPostProcessor型別)。該方法通常用於修改bean的定義,Bean的屬性值等,甚至可以在此快速初始化Bean。

而另外一個相關的擴充套件介面的BeanDefinitionRegistryPostProcessor,繼承自BeanFactoryPostProcessor,所有的Bean定義即將被載入,但Bean的例項還沒被建立時,也就是說,BeanDefinitionRegistryPostProcessorpostProcessBeanDefinitionRegistry方法執行時機先於BeanFactoryPostProcessorpostProcessBeanFactory方法。

區別於一個很類似的擴充套件介面BeanPostProcessor, 它的執行時機實在Bean初始化前後,新增一些自己想要的邏輯。

小結一下,上面關聯的擴充套件介面執行順序如下:1.BeanDefinitionRegistryPostProcessor,2.BeanFactoryPostProcessor,3.BeanPostProcessor。而BeanFactoryPostProcessor主要是在標準的BeanDefinition已經準備完畢,可以去修改已有的BeanDefinition的相關屬性等。

如何使用BeanFactoryPostProcessor

  1. 新建一個測試bean

``` @Data @Component public class Student {

@Value("${user.username:alvin}")
private String username;

@Value("${user.age:12}")
private int age;

} ```

  1. 新建處理器實現BeanFactoryPostProcessor

``` @Component @Slf4j public class TestBeanFactoryPostProcessor implements BeanFactoryPostProcessor {

@Override
public void postProcessBeanFactory(ConfigurableListableBeanFactory beanFactory) throws BeansException {
    log.info("******************** TestBeanFactoryPostProcessor#postProcessBeanFactory ****************");
    log.info("******************** bean的數量:[{}] ****************", beanFactory.getBeanDefinitionCount());
    // 修改bean definition屬性資訊
    BeanDefinition userBeanDef = beanFactory.getBeanDefinition("student");
    userBeanDef.getPropertyValues().add("username", "cxw");

    // 快速初始化Bean
    User user = (User)beanFactory.getBean("student");
    log.info("student name: [{}]", user.getUsername());
}

} ```

  1. 驗證結論

bean的屬性被成功被修改了。

原始碼解析

介面定義

``` /* * Factory hook that allows for custom modification of an application context's * bean definitions, adapting the bean property values of the context's underlying * bean factory. * *

Useful for custom config files targeted at system administrators that * override bean properties configured in the application context. See * {@link PropertyResourceConfigurer} and its concrete implementations for * out-of-the-box solutions that address such configuration needs. * *

A {@code BeanFactoryPostProcessor} may interact with and modify bean * definitions, but never bean instances. Doing so may cause premature bean * instantiation, violating the container and causing unintended side-effects. * If bean instance interaction is required, consider implementing * {@link BeanPostProcessor} instead. * *

Registration

*

An {@code ApplicationContext} auto-detects {@code BeanFactoryPostProcessor} * beans in its bean definitions and applies them before any other beans get created. * A {@code BeanFactoryPostProcessor} may also be registered programmatically * with a {@code ConfigurableApplicationContext}. * *

Ordering

*

{@code BeanFactoryPostProcessor} beans that are autodetected in an * {@code ApplicationContext} will be ordered according to * {@link org.springframework.core.PriorityOrdered} and * {@link org.springframework.core.Ordered} semantics. In contrast, * {@code BeanFactoryPostProcessor} beans that are registered programmatically * with a {@code ConfigurableApplicationContext} will be applied in the order of * registration; any ordering semantics expressed through implementing the * {@code PriorityOrdered} or {@code Ordered} interface will be ignored for * programmatically registered post-processors. Furthermore, the * {@link org.springframework.core.annotation.Order @Order} annotation is not * taken into account for {@code BeanFactoryPostProcessor} beans. * * @author Juergen Hoeller * @author Sam Brannen * @since 06.07.2003 * @see BeanPostProcessor * @see PropertyResourceConfigurer / @FunctionalInterface public interface BeanFactoryPostProcessor {

/**
 * Modify the application context's internal bean factory after its standard
 * initialization. All bean definitions will have been loaded, but no beans
 * will have been instantiated yet. This allows for overriding or adding
 * properties even to eager-initializing beans.
 * @param beanFactory the bean factory used by the application context
 * @throws org.springframework.beans.BeansException in case of errors
 */
void postProcessBeanFactory(ConfigurableListableBeanFactory beanFactory) throws BeansException;

} ```

介面的註釋很清楚的說明了它的作用和細節,大致有下面幾點:

  • 該介面允許使用者自定義修改工廠bean中的BeanDefinition, 調整BeanDefinition的屬性值,甚至初始化Bean。比如內建的PropertyResourceConfigurer,就是修改beanDefinition的屬性為配置檔案的屬性。
  • 該介面主要是用於修改BeanDefinition, 雖然也可以直接進行例項化Bean, 但是不建議這麼做,可能會造成其他未知的錯誤。

執行流程

其中核心邏輯是PostProcessorRegistrationDelegate#invokeBeanFactoryPostProcessors方法,該方法的前面部分邏輯主要是處理BeanDefinitionRegistryPostProcessorpostProcessBeanDefinitionRegistry方法,也就是想BeanDefinition註冊中中心新增新的BeanDefinition。

``` public static void invokeBeanFactoryPostProcessors( ConfigurableListableBeanFactory beanFactory, List beanFactoryPostProcessors) {

    .......... 該部分是處理BeanDefinitionRegistryPostProcessor的postProcessBeanDefinitionRegistry相關邏輯,跳過, 可以看BeanDefinitionRegistryPostProcessor的解析


    // Do not initialize FactoryBeans here: We need to leave all regular beans
    // uninitialized to let the bean factory post-processors apply to them!
    // 獲取所有實現了BeanFactoryPostProcessor介面的bean name列表,前提是在BeanFactory的BeanDefinitions列表中包含對應的bean定義資訊。
    String[] postProcessorNames =
            beanFactory.getBeanNamesForType(BeanFactoryPostProcessor.class, true, false);

    // Separate between BeanFactoryPostProcessors that implement PriorityOrdered,
    // Ordered, and the rest.
    // 存放實現了PriorityOrdered介面的processor
    List<BeanFactoryPostProcessor> priorityOrderedPostProcessors = new ArrayList<>();
    // 存放實現了Ordered介面的processor
    List<String> orderedPostProcessorNames = new ArrayList<>();
    // 存放沒有實現排序的processor
    List<String> nonOrderedPostProcessorNames = new ArrayList<>();
    // 遍歷前面全量的bean name,將他們歸類,放到上面的容器中
    for (String ppName : postProcessorNames) {
        // 如果在第一階段已經被呼叫過,就不呼叫,第一階段主要是BeanDefinitionRegistryPostProcessor,它繼承了BeanFactoryPostProcessor,它會在第一階段呼叫。
        if (processedBeans.contains(ppName)) {
            // skip - already processed in first phase above
        }
        else if (beanFactory.isTypeMatch(ppName, PriorityOrdered.class)) {
            priorityOrderedPostProcessors.add(beanFactory.getBean(ppName, BeanFactoryPostProcessor.class));
        }
        else if (beanFactory.isTypeMatch(ppName, Ordered.class)) {
            orderedPostProcessorNames.add(ppName);
        }
        else {
            nonOrderedPostProcessorNames.add(ppName);
        }
    }

    // First, invoke the BeanFactoryPostProcessors that implement PriorityOrdered.
    // 首先執行實現了PriorityOrdered介面的processor,對它們進行排序
    sortPostProcessors(priorityOrderedPostProcessors, beanFactory);
    // 真實執行processor中的邏輯。
    invokeBeanFactoryPostProcessors(priorityOrderedPostProcessors, beanFactory);

    // Next, invoke the BeanFactoryPostProcessors that implement Ordered.
    // 其次執行實現了Ordered介面的processor,對它們進行排序後執行processor中的邏輯。
    List<BeanFactoryPostProcessor> orderedPostProcessors = new ArrayList<>(orderedPostProcessorNames.size());
    for (String postProcessorName : orderedPostProcessorNames) {
        orderedPostProcessors.add(beanFactory.getBean(postProcessorName, BeanFactoryPostProcessor.class));
    }
    sortPostProcessors(orderedPostProcessors, beanFactory);
    invokeBeanFactoryPostProcessors(orderedPostProcessors, beanFactory);

    // 最後執行,沒有順序要求的processor
    List<BeanFactoryPostProcessor> nonOrderedPostProcessors = new ArrayList<>(nonOrderedPostProcessorNames.size());
    for (String postProcessorName : nonOrderedPostProcessorNames) {
        nonOrderedPostProcessors.add(beanFactory.getBean(postProcessorName, BeanFactoryPostProcessor.class));
    }
    invokeBeanFactoryPostProcessors(nonOrderedPostProcessors, beanFactory);

    // Clear cached merged bean definitions since the post-processors might have
    // modified the original metadata, e.g. replacing placeholders in values...
    beanFactory.clearMetadataCache();
}

//呼叫processors中的postProcessBeanFactory方法 private static void invokeBeanFactoryPostProcessors( Collection<? extends BeanFactoryPostProcessor> postProcessors, ConfigurableListableBeanFactory beanFactory) {

    for (BeanFactoryPostProcessor postProcessor : postProcessors) {
        StartupStep postProcessBeanFactory = beanFactory.getApplicationStartup().start("spring.context.bean-factory.post-process")
                .tag("postProcessor", postProcessor::toString);
        postProcessor.postProcessBeanFactory(beanFactory);
        postProcessBeanFactory.end();
    }
}

```

小結

整個執行流程的原始碼還是比較清晰並且簡單的。重點提下下面兩個點:

  1. 我們自定義的BeanFactoryProcessor需要加上@Component等註解,為什麼?

看原始碼得知,String[] postProcessorNames = beanFactory.getBeanNamesForType(BeanFactoryPostProcessor.class, true, false);獲取所有實現了BeanFactoryPostProcessor的Bean Name, 前提所有的Bean都要被註冊到BeanDefinitionRegistry, 通過新增@Component, @Service等註解,可以將對應的Bean定義資訊註冊到BeanFactory中,方便後面例項化Bean。 那麼它是在什麼地方註冊的呢?可以看下ConfigurationClassPostProcessor類,它實現了BeanDefinitionRegistryPostProcessor,會掃描所有@Component, @Service等註解,將對應的Bean Definition註冊到BeanFactory中。

  1. 執行順序問題

我們可以通過實現PriorityOrdered, Ordered介面,控制BeanFactoryProcessor的執行順序,, 優先執行實現了PriorityOrdered介面,其次是Ordered,最後是沒有實現任何排序介面的processor。

內建的BeanFactoryPostProcessor

Spring內建了一個比較重要的BeanFactoryPostProcessorPlaceholderConfigurerSupport, 實現從配置檔案中獲取屬性。
