Activity的啟動過程
theme: cyanosis
開啟掘金成長之旅！這是我參與「掘金日新計劃 · 12 月更文挑戰」的第32天，點選檢視活動詳情
啟動一個Activity有兩個方法startActivity和startActivityForResult，前者最終會呼叫startActivityForResult因此直接對後者進行分析
1.Activity啟動的發起
``` //Activity#startActivityForResult public void startActivityForResult(@RequiresPermission Intent intent, int requestCode, @Nullable Bundle options) { if (mParent == null) { options = transferSpringboardActivityOptions(options); Instrumentation.ActivityResult ar = mInstrumentation.execStartActivity( this, mMainThread.getApplicationThread(), mToken, this, intent, requestCode, options); if (ar != null) { mMainThread.sendActivityResult( mToken, mEmbeddedID, requestCode, ar.getResultCode(), ar.getResultData()); } if (requestCode >= 0) { // If this start is requesting a result, we can avoid making // the activity visible until the result is received. Setting // this code during onCreate(Bundle savedInstanceState) or onResume() will keep the // activity hidden during this time, to avoid flickering. // This can only be done when a result is requested because // that guarantees we will get information back when the // activity is finished, no matter what happens to it. mStartedActivity = true; }
cancelInputsAndStartExitTransition(options);
// TODO Consider clearing/flushing other event sources and events for child windows.
} else {
if (options != null) {
mParent.startActivityFromChild(this, intent, requestCode, options);
} else {
// Note we want to go through this method for compatibility with
// existing applications that may have overridden it.
mParent.startActivityFromChild(this, intent, requestCode);
}
}
} ```
在mParent == null的判斷中有這麼一行程式碼mMainThread.getApplicationThread()，其中的getApplication就是ApplicationThread它是ActivityThread的內部類，整合IApplication.Stub，也是個Binder物件，ActivityThread和ApplicationThread在Activity的啟動過程中發揮著重要的作用。
接著再看一下mInstrumentation.execStartActivity做了什麼
//Instrumentation#execStartActivity
@UnsupportedAppUsage
public ActivityResult execStartActivity(
Context who, IBinder contextThread, IBinder token, Activity target,
Intent intent, int requestCode, Bundle options) {
IApplicationThread whoThread = (IApplicationThread) contextThread;
Uri referrer = target != null ? target.onProvideReferrer() : null;
if (referrer != null) {
intent.putExtra(Intent.EXTRA_REFERRER, referrer);
}
if (mActivityMonitors != null) {
synchronized (mSync) {
final int N = mActivityMonitors.size();
for (int i=0; i<N; i++) {
final ActivityMonitor am = mActivityMonitors.get(i);
ActivityResult result = null;
if (am.ignoreMatchingSpecificIntents()) {
result = am.onStartActivity(intent);
}
if (result != null) {
am.mHits++;
return result;
} else if (am.match(who, null, intent)) {
am.mHits++;
if (am.isBlocking()) {
return requestCode >= 0 ? am.getResult() : null;
}
break;
}
}
}
}
try {
intent.migrateExtraStreamToClipData(who);
intent.prepareToLeaveProcess(who);
int result = ActivityTaskManager.getService().startActivity(whoThread,
who.getBasePackageName(), who.getAttributionTag(), intent,
intent.resolveTypeIfNeeded(who.getContentResolver()), token,
target != null ? target.mEmbeddedID : null, requestCode, 0, null, options);
checkStartActivityResult(result, intent);
} catch (RemoteException e) {
throw new RuntimeException("Failure from system", e);
}
return null;
}
由上面的程式碼可知啟動Activity的真正實現是由ActivityTaskManager.getService().startActivity()完成的
``` //ActivityTaskManager#getService public static IActivityTaskManager getService() { return IActivityTaskManagerSingleton.get(); }
@UnsupportedAppUsage(trackingBug = 129726065)
private static final Singleton
ActivityTaskManager的主要工作就是管理Activity它接替了ActivityManager的一些工作。
看到Binder就可以明白了這裡是獲取一個跨程序服務，獲取的是ActivityTaskManagerService(ATMS)，它繼承自IActivityTaskManager.Stub，是個Binder物件並且通過單例提供服務。
ATMS就是管理Activity及其容器(任務、堆疊、顯示等)的系統服務,執行在系統服務程序(system_server)。
在execStartActivity方法中還有一個方法呼叫checkStartActivityResult
``` //Instrumentation#checkStartActivityResult @UnsupportedAppUsage(maxTargetSdk = Build.VERSION_CODES.P, trackingBug = 115609023) public static void checkStartActivityResult(int res, Object intent) { if (!ActivityManager.isStartResultFatalError(res)) { return; }
switch (res) {
case ActivityManager.START_INTENT_NOT_RESOLVED:
case ActivityManager.START_CLASS_NOT_FOUND:
if (intent instanceof Intent && ((Intent)intent).getComponent() != null)
throw new ActivityNotFoundException(
"Unable to find explicit activity class "
+ ((Intent)intent).getComponent().toShortString()
+ "; have you declared this activity in your AndroidManifest.xml?");
throw new ActivityNotFoundException(
"No Activity found to handle " + intent);
case ActivityManager.START_PERMISSION_DENIED:
throw new SecurityException("Not allowed to start activity "
+ intent);
case ActivityManager.START_FORWARD_AND_REQUEST_CONFLICT:
throw new AndroidRuntimeException(
"FORWARD_RESULT_FLAG used while also requesting a result");
case ActivityManager.START_NOT_ACTIVITY:
throw new IllegalArgumentException(
"PendingIntent is not an activity");
case ActivityManager.START_NOT_VOICE_COMPATIBLE:
throw new SecurityException(
"Starting under voice control not allowed for: " + intent);
case ActivityManager.START_VOICE_NOT_ACTIVE_SESSION:
throw new IllegalStateException(
"Session calling startVoiceActivity does not match active session");
case ActivityManager.START_VOICE_HIDDEN_SESSION:
throw new IllegalStateException(
"Cannot start voice activity on a hidden session");
case ActivityManager.START_ASSISTANT_NOT_ACTIVE_SESSION:
throw new IllegalStateException(
"Session calling startAssistantActivity does not match active session");
case ActivityManager.START_ASSISTANT_HIDDEN_SESSION:
throw new IllegalStateException(
"Cannot start assistant activity on a hidden session");
case ActivityManager.START_CANCELED:
throw new AndroidRuntimeException("Activity could not be started for "
+ intent);
default:
throw new AndroidRuntimeException("Unknown error code "
+ res + " when starting " + intent);
}
} ```
從checkStartActivityResult的程式碼中可以知道它的作用就是檢查啟動Activity的結果，無法正確啟動時就丟擲一個異常。
2.Activity的管理-ATMS
到這裡Activity的啟動流程就通過跨程序轉移到了ATMS中，接著分析ATMS中的startActivity方法
``` //ActivityTaskManagerService#startActivity @Override public final int startActivity(IApplicationThread caller, String callingPackage, Intent intent, String resolvedType, IBinder resultTo, String resultWho, int requestCode, int startFlags, ProfilerInfo profilerInfo, Bundle bOptions) { return startActivityAsUser(caller, callingPackage, intent, resolvedType, resultTo, resultWho, requestCode, startFlags, profilerInfo, bOptions, UserHandle.getCallingUserId()); }
//ActivityTaskManagerService#startActivityAsUser @Override public int startActivityAsUser(IApplicationThread caller, String callingPackage, Intent intent, String resolvedType, IBinder resultTo, String resultWho, int requestCode, int startFlags, ProfilerInfo profilerInfo, Bundle bOptions, int userId) { return startActivityAsUser(caller, callingPackage, intent, resolvedType, resultTo, resultWho, requestCode, startFlags, profilerInfo, bOptions, userId, true /validateIncomingUser/); }
//ActivityTaskManagerService#startActivityAsUser int startActivityAsUser(IApplicationThread caller, String callingPackage, Intent intent, String resolvedType, IBinder resultTo, String resultWho, int requestCode, int startFlags, ProfilerInfo profilerInfo, Bundle bOptions, int userId, boolean validateIncomingUser) { enforceNotIsolatedCaller("startActivityAsUser");
userId = getActivityStartController().checkTargetUser(userId, validateIncomingUser,
Binder.getCallingPid(), Binder.getCallingUid(), "startActivityAsUser");
// TODO: Switch to user app stacks here.
return getActivityStartController().obtainStarter(intent, "startActivityAsUser")
.setCaller(caller)
.setCallingPackage(callingPackage)
.setResolvedType(resolvedType)
.setResultTo(resultTo)
.setResultWho(resultWho)
.setRequestCode(requestCode)
.setStartFlags(startFlags)
.setProfilerInfo(profilerInfo)
.setActivityOptions(bOptions)
.setMayWait(userId)
.execute();
} ```
在ATMS中的startActivity方法中一層層的深入看到最終呼叫的是startActivityAsUser方法，這個方法中首先呼叫getActivityStartController.obtainStart獲取到ActivityStarter例項，然後呼叫一系列方法(setCaller()、setUserId())等，最後通過execute()方法啟動Activity
//ActivityStater#execute
int execute() {
try {
// TODO(b/64750076): Look into passing request directly to these methods to allow
// for transactional diffs and preprocessing.
if (mRequest.mayWait) {
return startActivityMayWait(mRequest.caller, mRequest.callingUid,
mRequest.callingPackage, mRequest.realCallingPid, mRequest.realCallingUid,
mRequest.intent, mRequest.resolvedType,
mRequest.voiceSession, mRequest.voiceInteractor, mRequest.resultTo,
mRequest.resultWho, mRequest.requestCode, mRequest.startFlags,
mRequest.profilerInfo, mRequest.waitResult, mRequest.globalConfig,
mRequest.activityOptions, mRequest.ignoreTargetSecurity, mRequest.userId,
mRequest.inTask, mRequest.reason,
mRequest.allowPendingRemoteAnimationRegistryLookup,
mRequest.originatingPendingIntent, mRequest.allowBackgroundActivityStart);
} else {
return startActivity(mRequest.caller, mRequest.intent, mRequest.ephemeralIntent,
mRequest.resolvedType, mRequest.activityInfo, mRequest.resolveInfo,
mRequest.voiceSession, mRequest.voiceInteractor, mRequest.resultTo,
mRequest.resultWho, mRequest.requestCode, mRequest.callingPid,
mRequest.callingUid, mRequest.callingPackage, mRequest.realCallingPid,
mRequest.realCallingUid, mRequest.startFlags, mRequest.activityOptions,
mRequest.ignoreTargetSecurity, mRequest.componentSpecified,
mRequest.outActivity, mRequest.inTask, mRequest.reason,
mRequest.allowPendingRemoteAnimationRegistryLookup,
mRequest.originatingPendingIntent, mRequest.allowBackgroundActivityStart);
}
} finally {
onExecutionComplete();
}
}
在execute中分了兩種情況，但是無論哪種情況最終都會進入到startActivity中，這個startActivity中呼叫startActivityUnchecked
``` //ActivityStarter#startActivity private int startActivity(final ActivityRecord r, ActivityRecord sourceRecord, IVoiceInteractionSession voiceSession, IVoiceInteractor voiceInteractor, int startFlags, boolean doResume, ActivityOptions options, TaskRecord inTask, ActivityRecord[] outActivity, boolean restrictedBgActivity) { int result = START_CANCELED; final ActivityStack startedActivityStack; try { mService.mWindowManager.deferSurfaceLayout(); result = startActivityUnchecked(r, sourceRecord, voiceSession, voiceInteractor, startFlags, doResume, options, inTask, outActivity, restrictedBgActivity); } finally { final ActivityStack currentStack = r.getActivityStack(); startedActivityStack = currentStack != null ? currentStack : mTargetStack;
if (ActivityManager.isStartResultSuccessful(result)) {
if (startedActivityStack != null) {
// If there is no state change (e.g. a resumed activity is reparented to
// top of another display) to trigger a visibility/configuration checking,
// we have to update the configuration for changing to different display.
final ActivityRecord currentTop =
startedActivityStack.topRunningActivityLocked();
if (currentTop != null && currentTop.shouldUpdateConfigForDisplayChanged()) {
mRootActivityContainer.ensureVisibilityAndConfig(
currentTop, currentTop.getDisplayId(),
true /* markFrozenIfConfigChanged */, false /* deferResume */);
}
}
} else {
// If we are not able to proceed, disassociate the activity from the task.
// Leaving an activity in an incomplete state can lead to issues, such as
// performing operations without a window container.
final ActivityStack stack = mStartActivity.getActivityStack();
if (stack != null) {
stack.finishActivityLocked(mStartActivity, RESULT_CANCELED,
null /* intentResultData */, "startActivity", true /* oomAdj */);
}
// Stack should also be detached from display and be removed if it's empty.
if (startedActivityStack != null && startedActivityStack.isAttached()
&& startedActivityStack.numActivities() == 0
&& !startedActivityStack.isActivityTypeHome()) {
startedActivityStack.remove();
}
}
mService.mWindowManager.continueSurfaceLayout();
}
postStartActivityProcessing(r, result, startedActivityStack);
return result;
} ```
然後在startActivityUnChecked方法中呼叫mRootActivityContainer.resumeFocusedStacksTopActivities
，RootActivityContainer是Android10新增的類，分擔了之前ActivityStackSupervisor的部分功能。
然後在resumeFocusedStacksTopActivites中進入了ActivityStack的resumeTopActivityUncheckedLocked方法中
``` //ActivityStack#resumeTopActivityUncheckedLocked //確保堆疊中最頂層的活動被恢復 @GuardedBy("mService") boolean resumeTopActivityUncheckedLocked(ActivityRecord prev, ActivityOptions options) { if (mInResumeTopActivity) { // Don't even start recursing. return false; }
boolean result = false;
try {
// Protect against recursion.
mInResumeTopActivity = true;
result = resumeTopActivityInnerLocked(prev, options);
// When resuming the top activity, it may be necessary to pause the top activity (for
// example, returning to the lock screen. We suppress the normal pause logic in
// {@link #resumeTopActivityUncheckedLocked}, since the top activity is resumed at the
// end. We call the {@link ActivityStackSupervisor#checkReadyForSleepLocked} again here
// to ensure any necessary pause logic occurs. In the case where the Activity will be
// shown regardless of the lock screen, the call to
// {@link ActivityStackSupervisor#checkReadyForSleepLocked} is skipped.
final ActivityRecord next = topRunningActivityLocked(true /* focusableOnly */);
if (next == null || !next.canTurnScreenOn()) {
checkReadyForSleep();
}
} finally {
mInResumeTopActivity = false;
}
return result;
} ```
在reumeToActivityUncheckedLocked方法中又進入了resumeTopActivityInnerLocked方法
``` //ActivityStack#resumeTopActivityInnerLocked private boolean resumeTopActivityInnerLocked(ActivityRecord prev, ActivityOptions options) { ... boolean pausing = getDisplay().pauseBackStacks(userLeaving, next, false); if (mResumedActivity != null) { if (DEBUG_STATES) Slog.d(TAG_STATES, "resumeTopActivityLocked: Pausing " + mResumedActivity); // 暫停上一個Activity pausing |= startPausingLocked(userLeaving, false, next, false); } ... //這裡next.attachedToProcess()，只有啟動了的Activity才會返回true if (next.attachedToProcess()) { ...
try {
final ClientTransaction transaction =
ClientTransaction.obtain(next.app.getThread(), next.appToken);
...
//啟動了的Activity就傳送ResumeActivityItem事務給客戶端了，後面會講到
transaction.setLifecycleStateRequest(
ResumeActivityItem.obtain(next.app.getReportedProcState(),
getDisplay().mDisplayContent.isNextTransitionForward()));
mService.getLifecycleManager().scheduleTransaction(transaction);
....
} catch (Exception e) {
....
mStackSupervisor.startSpecificActivityLocked(next, true, false);
return true;
}
....
} else {
....
if (SHOW_APP_STARTING_PREVIEW) {
//這裡就是 冷啟動時 出現白屏 的原因了：取根activity的主題背景 展示StartingWindow
next.showStartingWindow(null , false ,false);
}
// 繼續當前Activity，普通activity的正常啟動 關注這裡即可
mStackSupervisor.startSpecificActivityLocked(next, true, true);
}
return true;
} ```
這裡先暫停上一個Actiivty然後在執行建立Activity的工作，最終進入了ActivityStackSupervisor.startSpecificActivityLocked方法。這裡有個點注意下，啟動activity前呼叫了next.showStartingWindow方法來展示一個window，這就是 冷啟動時 出現白屏 的原因了。
``` //ActivityStackSupervisor#startSpecificActivityLocked void startSpecificActivityLocked(ActivityRecord r, boolean andResume, boolean checkConfig) { // Is this activity's application already running? final WindowProcessController wpc = mService.getProcessController(r.processName, r.info.applicationInfo.uid);
boolean knownToBeDead = false;
if (wpc != null && wpc.hasThread()) {
try {
realStartActivityLocked(r, wpc, andResume, checkConfig);
return;
} catch (RemoteException e) {
Slog.w(TAG, "Exception when starting activity "
+ r.intent.getComponent().flattenToShortString(), e);
}
knownToBeDead = true;
}
...
try {
if (Trace.isTagEnabled(TRACE_TAG_ACTIVITY_MANAGER)) {
Trace.traceBegin(TRACE_TAG_ACTIVITY_MANAGER, "dispatchingStartProcess:"
+ r.processName);
}
// 上面的wpc != null && wpc.hasThread()不滿足的話，說明沒有程序，就會取建立程序
final Message msg = PooledLambda.obtainMessage(
ActivityManagerInternal::startProcess, mService.mAmInternal, r.processName,
r.info.applicationInfo, knownToBeDead, "activity", r.intent.getComponent());
mService.mH.sendMessage(msg);
} finally {
Trace.traceEnd(TRACE_TAG_ACTIVITY_MANAGER);
}
} ```
這裡的判斷條件if (wpc != null && wpc.hasThread())的意思是是否啟動了應用程式，內部是通過IApplicationThread是否為空來判斷的，這裡只看應用已經被啟動的情況，這裡進入了realStartActivityLocked方法
``` //ActivityStackSupversion#realStartActivityLocked boolean realStartActivityLocked(ActivityRecord r, WindowProcessController proc, boolean andResume, boolean checkConfig) throws RemoteException {
...
// Create activity launch transaction.
final ClientTransaction clientTransaction = ClientTransaction.obtain(
proc.getThread(), r.appToken);
final DisplayContent dc = r.getDisplay().mDisplayContent;
clientTransaction.addCallback(LaunchActivityItem.obtain(new Intent(r.intent),
System.identityHashCode(r), r.info,
// TODO: Have this take the merged configuration instead of separate global
// and override configs.
mergedConfiguration.getGlobalConfiguration(),
mergedConfiguration.getOverrideConfiguration(), r.compat,
r.launchedFromPackage, task.voiceInteractor, proc.getReportedProcState(),
r.icicle, r.persistentState, results, newIntents,
dc.isNextTransitionForward(), proc.createProfilerInfoIfNeeded(),
r.assistToken));
// Set desired final state.
final ActivityLifecycleItem lifecycleItem;
if (andResume) {
lifecycleItem = ResumeActivityItem.obtain(dc.isNextTransitionForward());
} else {
lifecycleItem = PauseActivityItem.obtain();
}
clientTransaction.setLifecycleStateRequest(lifecycleItem);
// Schedule transaction.
mService.getLifecycleManager().scheduleTransaction(clientTransaction);
...
return true;
} ```
這個方法中獲取了ClientTransaction，它是一個容器，包含了等待客戶端處理的事務，客戶端接收後取出並執行。
然後使用clientTransaction.addCallback添加了LaunchActivityItem例項
//都是用來發送到客戶端的
private List<ClientTransactionItem> mActivityCallbacks;
public void addCallback(ClientTransactionItem activityCallback) {
if (mActivityCallbacks == null) {
mActivityCallbacks = new ArrayList<>();
}
mActivityCallbacks.add(activityCallback);
}
LauncherActivityItem又是什麼
```
public static LaunchActivityItem obtain(Intent intent, int ident, ActivityInfo info,
Configuration curConfig, Configuration overrideConfig, CompatibilityInfo compatInfo,
String referrer, IVoiceInteractor voiceInteractor, int procState, Bundle state,
PersistableBundle persistentState, List
return instance;
} ```
將LauncherActivityItem的例項新增到setValues中配置了各種引數。從名字可以知道它就是用來啟動Activity的，它又是怎麼發揮作用的呢？再回頭去看realStartActivityLocked，呼叫了
mService.getLifecycleManager().scheduleTransaction(clientTransaction);裡面的service就是ATMS，getLifecycleManager獲取的是ClientLifecycleManager例項，scheduleTransaction方法如下：
``` void scheduleTransaction(ClientTransaction transaction) throws RemoteException { final IApplicationThread client = transaction.getClient(); transaction.schedule(); if (!(client instanceof Binder)) { transaction.recycle(); } }
public void schedule() throws RemoteException { mClient.scheduleTransaction(this); } ```
呼叫的就是IApplicationThread的scheduleTransaction方法，因為IApplicationThread是ApplicationThread在系統程序中的代理所以真正執行的地方就是ApplicationThread，也就是說Activity的啟動操作又跨程序還給了客戶端。
總結一下，啟動Activity的操作從客戶端跨程序轉移到了ATMS中，然後ATMS通過ActivityStrater、ActivityStack、ActivityStackSupervisor對Activity任務、Activity棧，Activity管理後又用跨程序方式把正在啟動的過程轉移表到了客戶端。
3.切換執行緒及訊息處理
經過上面的分析進入了Application的scheduleTransaction，然後在Application的scheduleTransaction中可以看到又進入了ActivityThread的scheduleTransaction，ActvityThread的scheduleTransaction是在其父類CientTransactionHandler中
``` //ActivityThread#ApplicationThread#scheduleTransaction @Override public void scheduleTransaction(ClientTransaction transaction) throws RemoteException { ActivityThread.this.scheduleTransaction(transaction); }
//ClientTransactionHandler void scheduleTransaction(ClientTransaction transaction) { transaction.preExecute(this); sendMessage(ActivityThread.H.EXECUTE_TRANSACTION, transaction); } ```
sendMessage最終呼叫如下
private void sendMessage(int what, Object obj, int arg1, int arg2, int seq) {
if (DEBUG_MESSAGES) Slog.v(
TAG, "SCHEDULE " + mH.codeToString(what) + " arg1=" + arg1 + " arg2=" + arg2 +
"seq= " + seq);
Message msg = Message.obtain();
msg.what = what;
SomeArgs args = SomeArgs.obtain();
args.arg1 = obj;
args.argi1 = arg1;
args.argi2 = arg2;
args.argi3 = seq;
msg.obj = args;
mH.sendMessage(msg);
}
上面程式碼中sendMessage最終收益通過mH傳送了一個訊息，這個mH繼承自Handler，是Handler的一個子類，它利用sendMessage將訊息傳送到了主執行緒
class H extends Handler {
...
}
那麼mH又是從哪個執行緒傳送的呢？
這就要從ApplicationThread的sceduleTransaction方法中看起，因為sendMessage是通過它呼叫的，已知ApplicationThread是通過跨程序呼叫的因此可以得出結論ApplicationThread的scheduleTransaction的呼叫是在Binder執行緒池中。
到這裡，訊息就在主執行緒處理了，那麼又是怎麼處理Activity啟動的呢？回到ActivityThread的方法scheduleTransaction的實現中，也就是它的父類ClientTransactionHandler，在sendMessage方法中傳遞了一個what引數ActivityThread.H.EXECUTE_TRANSACTION，這塊就是啟動Activiy處理的地方，看一下它的實現
class H extends Handler {
public void handleMessage(Message msg) {
case EXECUTE_TRANSACTION:
final ClientTransaction transaction = (ClientTransaction) msg.obj;
mTransactionExecutor.execute(transaction);
if (isSystem()) {
// Client transactions inside system process are recycled on the client side
// instead of ClientLifecycleManager to avoid being cleared before this
// message is handled.
transaction.recycle();
}
// TODO(lifecycler): Recycle locally scheduled transactions.
break;
}
}
從原始碼得知他進入了TransactionExecutor的execute方法，然後在executeCallbacks方法中遍歷所有callback，然後呼叫了ClientTransactionItem的execute方法
``` //TransactionExecutor#execute public void execute(ClientTransaction transaction) { if (DEBUG_RESOLVER) Slog.d(TAG, tId(transaction) + "Start resolving transaction");
final IBinder token = transaction.getActivityToken();
...
executeCallbacks(transaction);
executeLifecycleState(transaction);
...
}
@VisibleForTesting
public void executeCallbacks(ClientTransaction transaction) {
final List
final IBinder token = transaction.getActivityToken();
ActivityClientRecord r = mTransactionHandler.getActivityClient(token);
// In case when post-execution state of the last callback matches the final state requested
// for the activity in this transaction, we won't do the last transition here and do it when
// moving to final state instead (because it may contain additional parameters from server).
final ActivityLifecycleItem finalStateRequest = transaction.getLifecycleStateRequest();
final int finalState = finalStateRequest != null ? finalStateRequest.getTargetState()
: UNDEFINED;
// Index of the last callback that requests some post-execution state.
final int lastCallbackRequestingState = lastCallbackRequestingState(transaction);
final int size = callbacks.size();
//遍歷所有callback
for (int i = 0; i < size; ++i) {
final ClientTransactionItem item = callbacks.get(i);
if (DEBUG_RESOLVER) Slog.d(TAG, tId(transaction) + "Resolving callback: " + item);
final int postExecutionState = item.getPostExecutionState();
final int closestPreExecutionState = mHelper.getClosestPreExecutionState(r,
item.getPostExecutionState());
if (closestPreExecutionState != UNDEFINED) {
cycleToPath(r, closestPreExecutionState, transaction);
}
item.execute(mTransactionHandler, token, mPendingActions);
item.postExecute(mTransactionHandler, token, mPendingActions);
if (r == null) {
// Launch activity request will create an activity record.
r = mTransactionHandler.getActivityClient(token);
}
if (postExecutionState != UNDEFINED && r != null) {
// Skip the very last transition and perform it by explicit state request instead.
final boolean shouldExcludeLastTransition =
i == lastCallbackRequestingState && finalState == postExecutionState;
cycleToPath(r, postExecutionState, shouldExcludeLastTransition, transaction);
}
}
} ```
ClientTransactionItem有個子類LauncherActivityItem，在它的裡面重寫了execute方法
@Override
public void execute(ClientTransactionHandler client, IBinder token,
PendingTransactionActions pendingActions) {
Trace.traceBegin(TRACE_TAG_ACTIVITY_MANAGER, "activityStart");
ActivityClientRecord r = new ActivityClientRecord(token, mIntent, mIdent, mInfo,
mOverrideConfig, mCompatInfo, mReferrer, mVoiceInteractor, mState, mPersistentState,
mPendingResults, mPendingNewIntents, mIsForward,
mProfilerInfo, client, mAssistToken);
client.handleLaunchActivity(r, pendingActions, null /* customIntent */);
Trace.traceEnd(TRACE_TAG_ACTIVITY_MANAGER);
}
程式碼中的client.handleLaunchActivity的client就是ClientTransactionHandler，是在TransactionExecutor構造方法傳入的，而TransactionExecutor的構造是在ActivityThread中完成的
//ActivityThread
private final TransactionExecutor mTransactionExecutor = new TransactionExecutor(this);
所以可以得出結論client的handleLaunchActivity就是ActivityThread的handleLauncherActivity方法。
總結：ApplicationThread把啟動Activity的操作通過mH切換到了主執行緒，走到了ActivityThread的hanldeLaunchActivity方法中。
4.Activity的啟動核心實現-初始化及生命週期
先看下ActivityThread中的handleLaunchActivity做了什麼
``` public Activity handleLaunchActivity(ActivityClientRecord r, PendingTransactionActions pendingActions, Intent customIntent) {
...
final Activity a = performLaunchActivity(r, customIntent);
...
} ```
``` private Activity performLaunchActivity(ActivityClientRecord r, Intent customIntent) { //獲取待啟動Activity的元件資訊 ActivityInfo aInfo = r.activityInfo; if (r.packageInfo == null) { r.packageInfo = getPackageInfo(aInfo.applicationInfo, r.compatInfo, Context.CONTEXT_INCLUDE_CODE); }
ComponentName component = r.intent.getComponent();
if (component == null) {
component = r.intent.resolveActivity(
mInitialApplication.getPackageManager());
r.intent.setComponent(component);
}
if (r.activityInfo.targetActivity != null) {
component = new ComponentName(r.activityInfo.packageName,
r.activityInfo.targetActivity);
}
ContextImpl appContext = createBaseContextForActivity(r);
Activity activity = null;
try {
java.lang.ClassLoader cl = appContext.getClassLoader();
//建立Activity例項
activity = mInstrumentation.newActivity(
cl, component.getClassName(), r.intent);
StrictMode.incrementExpectedActivityCount(activity.getClass());
r.intent.setExtrasClassLoader(cl);
r.intent.prepareToEnterProcess();
if (r.state != null) {
r.state.setClassLoader(cl);
}
} catch (Exception e) {
if (!mInstrumentation.onException(activity, e)) {
throw new RuntimeException(
"Unable to instantiate activity " + component
+ ": " + e.toString(), e);
}
}
try {
//獲取Application例項，如果有責直接返回如果沒有則建立
Application app = r.packageInfo.makeApplication(false, mInstrumentation);
if (localLOGV) Slog.v(TAG, "Performing launch of " + r);
if (localLOGV) Slog.v(
TAG, r + ": app=" + app
+ ", appName=" + app.getPackageName()
+ ", pkg=" + r.packageInfo.getPackageName()
+ ", comp=" + r.intent.getComponent().toShortString()
+ ", dir=" + r.packageInfo.getAppDir());
if (activity != null) {
CharSequence title = r.activityInfo.loadLabel(appContext.getPackageManager());
Configuration config = new Configuration(mCompatConfiguration);
if (r.overrideConfig != null) {
config.updateFrom(r.overrideConfig);
}
if (DEBUG_CONFIGURATION) Slog.v(TAG, "Launching activity "
+ r.activityInfo.name + " with config " + config);
Window window = null;
if (r.mPendingRemoveWindow != null && r.mPreserveWindow) {
window = r.mPendingRemoveWindow;
r.mPendingRemoveWindow = null;
r.mPendingRemoveWindowManager = null;
}
appContext.setOuterContext(activity);
//通過attach方法關聯Activity上下文環境
activity.attach(appContext, this, getInstrumentation(), r.token,
r.ident, app, r.intent, r.activityInfo, title, r.parent,
r.embeddedID, r.lastNonConfigurationInstances, config,
r.referrer, r.voiceInteractor, window, r.configCallback,
r.assistToken);
if (customIntent != null) {
activity.mIntent = customIntent;
}
r.lastNonConfigurationInstances = null;
checkAndBlockForNetworkAccess();
activity.mStartedActivity = false;
int theme = r.activityInfo.getThemeResource();
if (theme != 0) {
activity.setTheme(theme);
}
activity.mCalled = false;
//呼叫生命週期onCreate
if (r.isPersistable()) {
mInstrumentation.callActivityOnCreate(activity, r.state, r.persistentState);
} else {
mInstrumentation.callActivityOnCreate(activity, r.state);
}
if (!activity.mCalled) {
throw new SuperNotCalledException(
"Activity " + r.intent.getComponent().toShortString() +
" did not call through to super.onCreate()");
}
r.activity = activity;
}
r.setState(ON_CREATE);
// updatePendingActivityConfiguration() reads from mActivities to update
// ActivityClientRecord which runs in a different thread. Protect modifications to
// mActivities to avoid race.
synchronized (mResourcesManager) {
mActivities.put(r.token, r);
}
} catch (SuperNotCalledException e) {
throw e;
} catch (Exception e) {
if (!mInstrumentation.onException(activity, e)) {
throw new RuntimeException(
"Unable to start activity " + component
+ ": " + e.toString(), e);
}
}
return activity;
} ```
performLaunchActivity主要做了一下事情：
-
- 通過ActivityClientRecord獲取待啟動Activity 的元件資訊，例如主題，啟動模式等
- 通過mInstrumentation.newActivity建立Activity例項
- 通過LoadedApk的makeApplication建立Application，內部也是通過mInstrumentation使用類載入器，建立後就呼叫了Instrumentation.callApplicationOnCreate方法，也就是Application的onCreate方法
- 建立ContextImpl並通過activity.attach方法對重要資料進行初始化，關聯了Context的具體實現ContextImpl，attach內部還完成了Window建立，這樣Window接收到外部事件就可以傳遞給Activity了
- 呼叫Activty的onCreate方法，是通過mInstrumentation.callActivityOnCreate完成的。
Activity的其他生命週期是如何被呼叫的
-
- LaunchActivityItem 遠端App端的onCreate生命週期事務
- ResumeActivityItem 遠端App端的onResume生命週期事務
- PauseActivityItem 遠端App端的onPause生命週期事務
- StopActivityItem 遠端App端的onStop生命週期事務
- DestroyActivityItem 遠端App端onDestroy生命週期事務
另外梳理過程中涉及的幾個類：
-
- ClientTransaction：客戶端事務處理者
- ClientLifecycleManager：客戶端生命週期管理者
- TransactionExecutor：遠端通訊事務執行者
那麼我們再來看看ResumeActivityItem吧。
在ActivityStackSupervisor的realStartActivityLocked方法中呼叫了resumeActivityItem，再回到TransactionExecutor的execute方法中還有一個方法executeLifecyclestate，這個方法中祛除了ActivityLifecycleItem並呼叫了execute方法，這裡實際上呼叫的就是ResumeActivityItem方法，最終走到ActivityThread的hanleResumeActivity方法，在handleResumeActivity方法中內部會走onStart、onResume。
handleResumeActivity主要做了以下事情：
-
- 呼叫生命週期：通過performResumeActivity方法，內部呼叫生命週期onStart、onResume方法
- 設定檢視可見：通過activity.makeVisible方法，新增window、設定可見。（所以檢視的真正可見是在onResume方法之後）
